11/133

—
solo®
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Friends of Hue smart switch insert Busch-rotary dimmer ) ) ) ) ) ) )
3
2
7
6
5
4
Wall-mounted transmitter, 2 channel Flush-mounted, LED, 2-100 W
For Friends of Hue smart switch rocker 6736 FoH-8xx. With rotary control, two-way switch and soft-catch.
Smart light switch for wireless remote control of Philips 2-wire connection (neutral conductor not required)
Hue lamps. Optimised for dimming of retrofit LED lamps (LEDi).
For switching/dimming of Philips Hue lamps. For dimmable Retrofit-LEDs (LEDi).
For storing, recalling and dimming of max. 2 individual For dimmable Retrofit-LEDs (LEDi) with conventional or
light scenes. electronic transformers.
Battery-free and maintenance-free thanks to "Energy For incandescent lamps, 230 V tungsten halogen
Harvesting". lamps, low-voltage halogen lamps with conventional or
Maximum reliability due to Zigbee Mesh technology. electronic transformers and dimmable energy-saving
Requires Philips Hue Bridge v2 (square shape) and the halogen lamps.
latest Philips Hue app (v3.2 or later). Mix operaton of LEDi with conventional loads possible.
Can be combined with switch ranges carat®, Busch- Via mode switch adjustable between leading edge
dynasty®, pure stainless steel, solo®, Busch-axcent® and control and trailing edge control.
future® linear. Low-noise level by MOSFET transistors.
Can be freely mounted in the room using the enclosed With electronic short-circuit protection.
adhesive tape and mounting plate. With electronic overload protection.
Including fixing plate for mounting on smooth walls or With adjustable minimum brightness.
on switch boxes. Without cover plate.
Including mounting components: Double-sided tape + Rated voltage: 230 V~, + 10% / - 10%
decorative sticker. Rated frequency: 50 Hz/60 Hz
Nominal power: 2 - 100 W/VA (retrofit LED loads).
6716 U-500 2CKA006710A0014 1
Nominal power: 10 - 250 W/VA (non-LED loads).
Protection class (Device): IP 20
Rocker Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1, 11
For Friends of Hue smart switch insert 6716 U-500. British Standard EN 60669-2-1
Can be combined with switch ranges carat®, Busch-
dynasty®, pure stainless steel, solo®, Busch-axcent® and
future® linear. 6523 U-102-500 2CKA006512A0335 1/10
1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
2) In the case of conventional transformers, take ~20% transformer loss into account.
ivory white 6736 FoH-82 2CKA006730A0134 1
3) In case of electronic transformers, 5 % transformer losses.
studio white 6736 FoH-84 2CKA006730A0136 1 4) Also applicable for 1gang 2way installations.
5) Provided with terminal for net disconnection devices.
1
grey metallic ) 6736 FoH-803 2CKA006730A0137 1
6) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
1) Surface painted. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
7) Recommendation: Please use loads and types of one producer.
