solo®
Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
SCHUKO® socket outlet ) SCHUKO® socket outlet
with labelling field with LED control light
DP (2 P + E) Shuttered.
Size of labelling field: 60 x 9 mm. DP (2 P + E)
Rated voltage: 250 V~, Rated current: 16 A With transparent lens.
Protection class (Device): IP 20 LED colour green.
Rated voltage: 250 V~
ivory white 20 EUN-82 2CKA002011A3726 10 Rated current: 16 A
studio white 20 EUN-84-500 2CKA002011A6209 10/100 Protection class (Device): IP 20
grey metallic ) 20 EUN-803 2CKA002011A3876 10 ivory white 20 EUCBL-82 2CKA002013A5284 10
2
studio white 20 EUCBL-84 2CKA002013A5286 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Surface painted.
grey metallic ) 1 20 EUCBL-803 2CKA002013A5456 10
1) Surface painted.
1
SCHUKO® socket outlet ) )
2
with label field, increased shock protection
Size of labelling field: 60 x 9 mm. SCHUKO® socket outlet
With screwless terminals. with marking
DP (2 P + E) With screwless terminals.
Shuttered. DP (2 P + E)
Rated voltage: 250 V~, Rated current: 16 A Rated voltage: 250 V~
Protection class (Device): IP 20 Rated current: 16 A
Protection class (Device): IP 20
ivory white 20 EUCNB-82 2CKA002013A5428 10
Green, RAL 20 EUC-13-82-101 2CKA002011A6260 10
studio white 20 EUCNB-84-500 2CKA002013A5431 10/100
6032
grey metallic ) 20 EUCNB-803 2CKA002013A5426 10 11
3
orange RAL 20 EUC-14-82 2CKA002011A3723 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. 2004
2) Increased shock protection .
3) Surface painted.
Busch-Object socket outlet ) 1
shuttered
SCHUKO® socket outlet ) With screwless terminals.
1
with marking "EDV" DP (2 P + E)
With screwless terminals. Incl. Cover plate with extract mechanism.
DP (2 P + E) Rated voltage: 250 V~
Shuttered. Rated current: 16 A
Rated voltage: 250 V~, Rated current: 16 A Protection class (Device): IP 20
Protection class (Device): IP 20
ivory white 20 EUAB-82 2CKA002013A5405 10
ivory white 20 EUCKS/DV-82 2CKA002013A5267 10
studio white 20 EUAB-84 2CKA002013A5407 10
studio white 20 EUCKS/DV-84 2CKA002013A5268 10
grey metallic ) 2 20 EUAB-803 2CKA002013A5403 10
2
grey metallic ) 20 EUCKS/DV-803 2CKA002013A5462 10/100
1) Increased shock protection .
1) Increased shock protection .
2) Surface painted.
3) Surface painted.
2
FI-SCHUKOMAT, SCHUKO® socket outlet (RCD) ) ) )
1
3
Busch-Protector® SCHUKO® socket outlet ) 1 with earth leakage circuit breaker
with overvoltage protection Shuttered.
DP (2 P + E) DP cut off (P,N)
With integrated and external signalling contact.
ISN = 5 kA. Device protection for technical sensitive Without PE monitoring.
equipment such as computer, entertainment electronics With connecting conductor and protection of
and building management systems. downstream socket outlets.
Rated fault current: 30 mA.
Effectively reduces overvoltage peaks occurring With fixing claws.
between the sub-distribution switch board and Rated frequency: 45-60 Hz.
SCHUKO® socket outlet. Rated voltage: 230 V~
Arrestor test class: classification Type 2 Rated current: 16 A
Rated voltage: 250 V~, Secondary: 250 V~ Protection class (Device): IP 20
Rated current: 16 A Temperature range (Device): -25 °C to 40 °C
Protection class (Device): IP 20
ivory white 3120 EUCB-82 2CKA003116A0661 1
ivory white 2310 EUGL/VA-82-11 2CKA002011A3831 1
studio white 3120 EUCB-84 2CKA003116A0662 1
studio white 2310 EUGL/VA-84-11 2CKA002011A3833 1
grey metallic ) 3120 EUCB-803 2CKA003116A0666 1/10
4
grey metallic ) 2310EUGL/VA-803-112CKA002011A3877 1
2
1) Connecting terminals approved in accordance with VDE 0620-1 as connectors.
red RAL 3020 2310 EUGL/ 2CKA002011A6257 1/10 2) Protective measure according to VDE 0100; can be proven or checked using the
VA-12-82-101 Profitest 0100S testing device, for example.
1) Connecting terminals approved in accordance with VDE 0620-1 as connectors. 3) Increased shock protection .
2) Surface painted. 4) Surface painted.
