solo®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Comfort timer control element ) 1 Time switch mechanism 16 A ) )
1
2
For manual and time-controlled switching of blinds, DP, break contact for staircases, exterior lighting, fans,
roller blinds, awnings, lighting and other electrical etc.
devices. Running time: 120 min
With dusk to dawn program including (Astro-program) For time-programmed switching of electrical
Individual Astro adjustment and Astro blocking time. consumers.
The controlled devices can be manually operated at any Rated voltage: 230 V~, +10 % / -10 %
time. Rated current: 16 A, cos φ 0.25
Simple setting via high-resolution display with Protection class (Device): IP 20
background illumination. 1071 U 2CKA001043A0124 1
With preset switching times/date/time.
Factory-set switching times can be individually 1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
adjusted. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
Automatic switchover from summer time to winter time or 3060 wallbox concrete)
(switch-off function).
Switching times/programme are safely stored in the
event of a mains power failure. Cover plate
Power reserve for time and date > 10 years. For comfort timer control element 6455-101-500.
Simple toggling between manual/automatic/vacation For standard timer control element 6456-101.
modes. For room thermostats 1098 U-101 and 1098 UF-101.
Combined with Busch-Blind control II insert For short-time timer 6465 U-101.
6411 U/S-101, sun protection and twilight function. For Busch-CO2 sensor 1091 U-500.
Freely adjustable temperature and brightness-
dependent sun protection function. ivory white 6435-82 2CKA006430A0304 10
Freely adjustable twilight function. studio white 6435-84 2CKA006430A0306 10
User-adjustable running times for blinds and air grey metallic ) 1 6435-803 2CKA006430A0351 10
conditioning. 11
Programming possible only with control element 1) Surface painted.
attached and energized.
6 switching times per day can be user-defined for each Cover plate
day of the week. with rotary knob, with marking
Astro switching times and switching times can be For Busch-Timer insert 1070 U.
combined. Running time: 15 min
When combined with LED dimmer 6524 U, Busch- Protection class (Device): IP 20
Universal master dimmer insert 6593 U or Busch-
Memory touch-type controller 6550 U-101, the
brightness of the lighting can be adjusted for each ON ivory white 1770-82-103 2CKA001753A0256 10
switching time.
For Busch-Blind control II insert 6411 U-101, studio white 1770-84-103 2CKA001753A0258 10
6411 U/S-101. grey metallic ) 1 1770-803-103 2CKA001753A0254 10
For Busch-Universal relay switch insert 6401 U-102. 1) Surface painted.
For Busch-Universal master dimmer insert 6593 U.
For LED dimmer insert 6524 U and 6526 U..
For Busch-Memory touch-type controller 6550 U-101. Cover plate
Temperature range (Device): 0 °C to 35 °C with rotary knob, with marking
For Busch-Timer insert 1071 U.
6455-101-500 2CKA006410A0399 1/10
Running time: 120 min
1) See respective cover plates 6435-xx.
Protection class (Device): IP 20
Time switch mechanism 16 A ) ) ivory white 1771-82-103 2CKA001753A0266 10
2
1
DP, break contact for staircases, exterior lighting, fans,
etc. studio white 1771-84-103 2CKA001753A0301 10
Running time: 15 min grey metallic ) 1 1771-803-103 2CKA001753A0264 10
For time-programmed switching of electrical 1) Surface painted.
consumers.
Rated voltage: 230 V~, +10 % / -10 %
Rated current: 16 A, cos φ 0.25
Protection class (Device): IP 20
1070 U 2CKA001043A0025 1/10
1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
