11/144 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
solo®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Key Switch Insert ) ) ) Blind switch insert ) )
2
3
1
breaking circuit, 1-pole With rotary knob/push button.
For profile semi-cylindrical lock. Rated voltage: 250 V~
In switched-on and switched-off status the key can be Rated current: 10 A
pulled out in the central position, respectively. Protection class (Device): IP 20
Delivered without cylindrical lock. IEC60669-1, British Standard EN 60669-1
Rated voltage: 250 V~
Rated current: 10 AX DP )
3
Protection class (Device): IP 20IEC60669-1, British
Standard EN 60669-1 2722 U 2CKA001101A0559 10
2733 USL-101 2CKA001101A0914 10 SP, N, E
Mounting 35 mm deep flush 1gang 2723 U 2CKA001101A0567 10
boxes: or Dual Box 3070-2/35 BSDB. 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
2gang product 2gang combination with adapter plate Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
combinations: APBS in Dual Box only. or 3060 wallbox concrete)
2) Blind switches/push switches prevents fast change over between operating
neon indicator: not applicable directions.
delivery form: Adapter plate APBS to be ordered separate. 3) Also suitable for controlling direct voltage drives.
1) For installation on British Standard wallboxes please use adapter plate APBS
(6599-0-2813). (Depth of box 60 mm.) Blind switch/push-switch ) ) ) )
3
4
2
1
2) Use the cylindrical lock according to the enclosed drawing. For profile semi-cylindrical lock/switch and push-switch.
3) See profile semi-cylindrical lock.
Delivered without cylindrical lock.
Rated voltage: 250 V~
Blind switch insert ) ) Rated current: 10 AX
1
2
With interlock. Protection class (Device): IP 20
11
Rated voltage: 250 V~ IEC60669-1, British Standard EN 60669-1
Rated current: 10 AX
5
IEC60669-1, British Standard EN 60669-1 DP )
2712 USL-101 2CKA001101A0872 10
SP, switch SP, N, E
2000/4 US-500 2CKA001012A2197 10/100 2713 USL-101 2CKA001101A0880 10
1) For installation on British Standard wallboxes please use adapter plate APBS
SP, push switch.
(6599-0-2813). (Depth of box 60 mm.)
2020/4 US-500 2CKA001413A1103 10/100 2) Blind switches/push switches prevents fast change over between operating
directions.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
3) Use the cylindrical lock according to the enclosed drawing.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 4) See semi-cylindrical lock.
or 3060 wallbox concrete) 5) Also suitable for controlling direct voltage drives.
2) These blind switches/push buttons safely prevent a switch-over of the running
direction being carried out too quickly.
Blind switch insert ) ) ) )
4
1
2
3
2
Blind switch insert ) ) For profile semi-cylindrical lock/push-button.
1
With rotary knob/switch and push switch. Delivered without cylindrical lock.
Rated voltage: 250 V~ Rated voltage: 250 V~
Rated current: 10 AX Rated current: 10 A
Protection class (Device): IP 20 Protection class (Device): IP 20
IEC 60669-1, British Standard EN 60669-1 British Standard EN 60669-1, IEC60669-1
DP )
5
3
DP )
2722 USL-101 2CKA001101A0898 10
2712 U 2CKA001101A0534 10
SP, N, E
SP, N, E
2723 USL-101 2CKA001101A0906 10
2713 U 2CKA001101A0542 10
1) For installation on British Standard wallboxes please use adapter plate APBS
Mounting 35 mm deep flush 1gang (6599-0-2813). (Depth of box 60 mm.)
boxes: or Dual Box 3070-2/35 BSDB. 2) Blind switches/push switches prevents fast change over between operating
directions.
2gang product 2gang combination with adapter plate APBS in Dual Box 3) Use the cylindrical lock according to the enclosed drawing.
combinations: only. 4) See semi-cylindrical lock.
neon indicator: not applicable 5) Also suitable for controlling direct voltage drives.
delivery form: Adapter plate APBS to be ordered separate.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Blind switches/push switches prevents fast change over between operating
directions.
3) Also suitable for controlling direct voltage drives.
