solo®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Short-time timer insert ) 1 Control element
countdown timer For Busch-Blind control II insert 6411 U-101,
For time-programmed switching of electrical 6411 U/S-101.
consumers. For basic blind insert 6418 U.
With control cover, without cover plate. For Busch-Universal 2gang 1way insert 6402 U.
Minimum timer time: 1 second.
Maximum timer time: 9:59:59 hours.
Rated voltage: 230 V~, +10 % / -10 % ivory white 6430-82-102 2CKA006430A0327 1/10
Rated frequency: 50 Hz studio white 6430-84-102-500 2CKA006430A0400 1/10
Outputs: 1x Normally open contact grey metallic ) 1 6430-803-102 2CKA006430A0350 1/10
Rated current: 10 A, cos φ 1
Rated power: 2300 VA 1) Surface painted.
Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1, Cover plate )
1
British Standard EN 60669-2-1
with rotary knob
6465 U-101-500 2CKA006410A0393 1/10 For comfort blinds insert 6419 U.
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
Cover frames: 1gang frame 1721 BS-2xG
or Dual Box frame 1722 BSDB-2xG. ivory white 6436-82 2CKA006430A0356 10
2gang product 2gang combination with adapter plate studio white 6436-84 2CKA006430A0358 10
combinations: APBS in Dual Box only. grey metallic ) 2 6436-803 2CKA006430A0360 10
neon indicator: not applicable 1) Continuous lighting of the turn knob possible using glow lamp 3855. Not included
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, in delivery. Neutral wire required for operation with neon lamp.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 2) Surface painted.
11
or 3060 wallbox concrete)
Standard timer control element )
1
Rocker For manual and time-controlled switching of blinds and
with marking roller blinds.
As cover for flush-mounted blind control switch/push With dusk to dawn program including (Astro-program)
switch. Individual Astro adjustment and Astro blocking time.
For inserts 2000/4 and 2020/4 US. The controlled devices can be manually operated at any
Protection class (Device): IP 20 time.
Simple setting via high-resolution display with
ivory white 1785 JA-82 2CKA001751A2748 10 background illumination.
studio white 1785 JA-84-500 2CKA001751A3088 10/100 With preset switching times/date/time.
Factory-set switching times can be individually
grey metallic ) 1785 JA-803 2CKA001751A3020 10
1
adjusted.
1) Surface painted. Automatic switchover from summer time to winter time
(switch-off function).
Switching times/programme are safely stored in the
Cover plate event of a mains power failure.
with rotary control, with marking Power reserve for time and date > 10 years.
As cover for flush-mounted blind control switch/push Simple toggling between manual/automatic/vacation
switch. modes.
For inserts 2712 U, 2713 U and 2722 U, 2723 U. Programming possible only with control element
Protection class (Device): IP 20
attached and energized.
ivory white 1740-82 2CKA001710A3154 10 2 switching times per day can be user-defined for each
day of the week.
studio white 1740-84 2CKA001710A3172 10/100
Astro switching times and switching times can be
grey metallic ) 1740-803 2CKA001710A3840 10 combined.
1
1) Surface painted. For basic blind insert 6418 U.
Temperature range (Device): 0 °C to 35 °C
6456-101 2CKA006410A0398 1/10
Cover plate ) 1
with labelling field 1) See respective cover plates 6435-xx.
With marking.
For half-cylindrical type switches and blind control
switch/push-switch.
For inserts 2733 USL-101 and 2712 USL-101, 2713 USL-101,
2722 USL-101, 2723 USL-101.
Protection class (Device): IP 20
ivory white 1755 SL/PZ-82-101 2CKA001710A3157 10
studio white 1755 SL/PZ-84-101 2CKA001710A3175 10
2
grey metallic ) 1755 SL/PZ-803-101 2CKA001710A3841 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Surface painted.
