solo®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
VGA connection unit ) F duct-jack
with screw-type terminals and strain relief for communication adapter
Suitable for telephone connection unit cover plates For connection of antenna cables e.g.. for TVs with
2539-21x and 1766-xxx. integrated TV-tuner and satellite receiver.
To link analogue video data between PCs and laptops to With screw-type terminals.
monitors or digital projectors etc. For trunk systems, flush-mounted wall boxes and
VGA-type: D-type, 15-pole. underfloor systems.
Fully HD ready (1920 x 1080 pixel). Protection class (Device): IP 20
For 15-wire VGA-cables via srew-type terminals. metal clad 0262-500 2CKA000230A0440 1
For trunk systems, flush-mounted wall boxes and
underfloor systems.
For easy installation and to follow the valid bending Communication adapter
radii the "Kaiser- electronic-wall-box" type 1068-02 or for Cinch-jacks
9062-74 is recommended. Suitable for telephone connection unit cover plates
Without cover plate. 2539-21x and 1766-xxx.
Without claws. To support 1 or 2 jacks.
Protection class (Device): IP 20 For trunk systems, flush-mounted wall boxes and
Mounting depth: 34 mm underfloor systems.
white 0261/21-500 2CKA000230A0424 1 Without cover plate.
Without claws.
grey 0261/23-500 2CKA000230A0426 1 Protection class (Device): IP 20
alpine white 0261/22-500 2CKA000230A0425 1
white 0263/11-500 2CKA000230A0444 1
1) Please follow the recommendations of the cable and device producers for the max.
VGA cable lengths. grey 0263/13-500 2CKA000230A0446 1
alpine white 0263/12-500 2CKA000230A0445 1
USB connection unit )
1
11
with screw-type terminals and strain relief Cinch-jacks
Suitable for telephone connection unit cover plates for communication adapter
2539-21x and 1766-xxx. To link analogue audio devices like audio-receiver,
To link mobile devices like e.g. printer, scanner, USB- amplifier and HiFi-sets.
sticks or digital cameras etc. Audio-band 20Hz - 20kHz.
USB-type A, USB 2.0 compatible. Marked white: audio , channel left.
For 5-wire USB- cables via srew-type terminals. With soldering tag.
For trunk systems, flush-mounted wall boxes and Protection class (Device): IP 20
underfloor systems. alpine white 0263/04-500 2CKA000230A0451 1
For easy installation and to follow the valid bending
radii the "Kaiser- electronic-wall-box" type 1068-02 or
9062-74 is recommended. Cinch-jacks
Without cover plate. for communication adapter
Without claws. To link analogue audio devices like audio-receiver,
Protection class (Device): IP 20 amplifier and HiFi-sets.
Mounting depth: 34 mm Audio-band 20Hz - 20kHz.
white 0261/11-500 2CKA000230A0418 1 Marked black: audio , channel left.
With soldering tag.
grey 0261/13-500 2CKA000230A0420 1
Protection class (Device): IP 20
alpine white 0261/12-500 2CKA000230A0419 1
black 0263/05-500 2CKA000230A0452 1
1) Please follow the recommendations of the cable and device producers for the max.
USB cable lengths.
Cinch-jacks
for communication adapter
Communication adapter To link analogue audio devices like audio-receiver,
for BNC-F Duct-jacks amplifier and HiFi-sets.
Suitable for telephone connection unit cover plates Audio-band 20Hz - 20kHz.
2539-21x and 1766-xxx. Marked red: audio , channel left.
To support 1 or 2 jacks. With soldering tag.
For trunk systems, flush-mounted wall boxes and Protection class (Device): IP 20
underfloor systems.
Without cover plate. Red 0263/06-500 2CKA000230A0453 1
Without claws.
Protection class (Device): IP 20
Cinch-jacks
white 0262/11-500 2CKA000230A0436 1 for communication adapter
grey 0262/13-500 2CKA000230A0438 1 For connecting analogue video devices, such as
DVD players, hard disc recorders, video recorders or
alpine white 0262/12-500 2CKA000230A0437 1 receivers.
Marked yellow: audio , channel left.
With soldering tag.
Protection class (Device): IP 20
yellow 0263/07-500 2CKA000230A0454 1
