Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
2
Room thermostat, flush-mounted ) ) ) Room thermostat, flush-mounted ) )
3
2
1
Change-over contact, setpoint indication, timer Change-over contact, setpoint indication, timer,
With change-over contact. remote sensor
Easy adjustment using menu and text-based display. With change-over contact.
4 switching times per day can be user-defined for each Easy adjustment using menu and text-based display.
day of the week. 4 switching times per day can be user-defined for each
With fixing claws. day of the week.
Automatic summer/wintertime switch-over With fixing claws.
Power reserve > 10 hours. Automatic summer/wintertime switch-over
To fit cover plate 6435-xxx. Remote sensor cable length: 4 m.
Class of temperature controller 1 Sensor =NTC, 10 kilo-ohm at 25 degrees C.
Contribution to space heating energy efficiency 1,0%. Power reserve > 10 hours
Rated voltage: 230 V~ To fit cover plate 6435-xxx.
Rated current: 10 A Class of temperature controller 1
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9 Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~
1098 U-101 2CKA001032A0508 1/10
Rated current: 16 A
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, Temperature range (Device): 10 °C to 50 °CEN 60730-2-9
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete) 1098 UF-101 2CKA001032A0509 1/10
2) Servo valves of "closed or open when de-energized“ design are required for the
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
controller. E.g. article no. 6164/10-101. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
3) Switching temperature difference: ± 0.5 K.
or 3060 wallbox concrete)
2) Servo valves of "closed or open when de-energized“ design are required for the
controller. E.g. article no. 6164/10-101.
1
Room thermostat, flush-mounted )
Remote sensor
With remote sensor and thermal feedback Room thermostat, flush-mounted ) ) ) 3
1
2
11
For underfloor heating. Heating/cooling
With built-in slide switch and control lamp for nightly With separate connection (230 V~) for external
reduction of 4 K. switchover between heating or cooling.
Switch contact opens when the set temperature is Switch contact opens when the set temperature is
reached. reached.
With fixing claws. With fixing claws.
Remote sensor cable length: 4 m. Nominal current: 10 A heating
Sensor =NTC, 10 kilo-ohm at 25 degrees C. Nominal current: 5 A cooling
Adjusting range: +10 to +50° C. Class of temperature controller 1
Connecting cable: 1mm² to 2.5 mm² Contribution to space heating energy efficiency 1,0%.
Separate terminal to activate nighttime mode and Rated voltage: 230 V~
reduction of room temperature by 4K. Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
Class of temperature controller 1 British Standard EN 60669-2-1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~ 1099 UHK 2CKA001032A0515 1/10
Rated current: 16 A, cos φ 1EN 60730-2-9, British 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Standard EN 60669-2-1 Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
1095 UF 2CKA001032A0497 1/10 2) Servo-valves, "closed when de-energized", are necessary for connection to
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
Room thermostat, flush-mounted ) ) ) 3
1
2
Heating/cooling, sliding switch
With built-in sliding switch for switchover between
cooling or heating.
Switch contact opens when the set temperature is
reached.
With fixing claws.
Nominal current: 10 A heating
Nominal current: 5 A cooling
Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
1099 UHKEA 2CKA001032A0516 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
