solo®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Communication adapter Cover plate
for Mini-jacks 3,5mm. For Busch-DigitalRadio 8215 U/8216 U.
Suitable for telephone connection unit cover plates For Busch-Radio iNet 8216 U.
2539-21x and 1766-xxx. For Busch-Radio BTconnect 8217 U.
To support 1 or 2 jacks.
For trunk systems, flush-mounted wall boxes and
underfloor systems.
Without cover plate. ivory white 8252-82 2CKA008200A0051 10
Without claws. studio white 8252-84 2CKA008200A0053 10
Protection class (Device): IP 20
grey metallic ) 1 8252-803 2CKA008200A0112 10
white 0264/11-500 2CKA000230A0458 1 1) Surface painted.
grey 0264/13-500 2CKA000230A0460 1
alpine white 0264/12-500 2CKA000230A0459 1 Cover plate
For loudspeaker insert 8223 U.
Mini-jack 3,5 mm
for communication adapter
For the connection of mobile terminal devices such as
MP3 player (stereo), mobile telephone and smartphones.
Audio-band 20Hz - 20kHz. ivory white 8253-82 2CKA008200A0079 1/10
With soldering tag.
Protection class (Device): IP 20 studio white 8253-84 2CKA008200A0081 1/10
grey metallic ) 1 8253-803 2CKA008200A0115 1/10
chrome gloss 0264-500 2CKA000230A0462 1
1) Surface painted.
11
1
Stereo loudspeaker connection box )
With screwless terminals (with screw-type terminals on Cover plate
the back). For telephone connection unit.
With 4 terminals. For USB, VGA, HDMI inserts and communication
Cable cross-section max. 10 mm2. adapter.
Polarity is indicated by color. For loudspeaker connection box.
With claw. USB power adapter insert 6472 U.
Protection class (Device): IP 20 Suitable for part number 0248/0x-101.
For data modules.
white 0248/02-101 2CKA000230A0402 10/100 Suitable for Art. No. 0219/12 and 0219/13.
1) Suitable for cover telephone unit 1766-xxx and 2539-21x. For modular outlets with 90° RJ45 outlet from
Telegärtner (type MJ and WE).
Protection class (Device): IP 20
Stereo loudspeaker connection box )
1
With screwless terminals (with screw-type terminals on ivory white 1766-82 2CKA001710A3144 10/100
the back). studio white 1766-84-500 2CKA001710A3992 10/100
With 4 terminals. 1
Cable cross-section max. 10 mm2. grey metallic ) 1766-803 2CKA001710A3854 10
Polarity is indicated by color. 1) Surface painted.
With claw.
Protection class (Device): IP 20
Cover plate
alpine white 0248/04-101-500 2CKA000230A0464 10/100 With metal mounting plate, with fixing claws,
1) Suitable for cover telephone unit 1766-xxx and 2539-21x. loudspeaker terminals and cover.
Conductor cross-sections up to 4 mm² rigid.
With screw-type terminals.
1
Stereo loudspeaker connection box ) Protection class (Device): IP 20
With screwless terminals (with screw-type terminals on
the back). ivory white 1751-82 2CKA001723A0239 10
With 4 terminals. studio white 1751-84 2CKA001723A0240 10/100
Cable cross-section max. 10 mm2. 1
Polarity is indicated by color. grey metallic ) 1751-803 2CKA001723A0257 10
With claw. 1) Surface painted.
Protection class (Device): IP 20
anthracite 0248/05-101 2CKA000230A0404 10/100 Cover plate
1) Suitable for cover telephone unit 1766-xxx and 2539-21x. with rotary control, with marking
As a cover for volume controllers.
Suitable for the "LR 15 mono BJ UP" devices of WHD.
Protection class (Device): IP 20

ivory white 1740 DR/03-82 2CKA001710A3807 10
studio white 1740 DR/03-84 2CKA001710A3808 10
grey metallic ) 1 1740 DR/03-803 2CKA001710A4119 10
1) Surface painted.
