solo®
WaveLINE control elements Busch-Infoline®

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
Wall-mounted transmitter WaveLINE ) ) Cover plate ) )
1
2
1
4-channel 1gang, with labelling field
4gang wall-mounted transmitter independent of mains With operating knob.
power supply. For signal/cancel push-button 1520/1 UK.
With labelling field and labelling strip. For monitoring unit 1511 U.
For switching and dimming. For Busch-Leakage guard insert 1531 U.
For controlling blinds and light scenes. With labelling field 61 x 20 mm.
4 radio channels can be operated or up to 8 light scenes Protection class (Device): IP 20
can be called up. Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
For flush-mounted WaveLINE actuators 6701-101, 6702, studio white 1571 CN-84 2CKA001582A0346 10
6703, 6704 and 6705-101.
For LED display WaveLINE 6730-xxx. 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Can also be used for Busch-axcent®, solo®, and carat®.
Compatible with WaveLINE KNX gateway TP-RF 6770.
Send frequency: 868 MHz.
Free-field range: approx. 100 m. Cover plate ) )
2
1
Power supply: lithium button cell battery Type CR2032. 2gang, with labelling field
Battery service life: typically 5 years, therefore With operating knob.
practically maintenance-free. For signal push-button insert 1520/1 UKZ.
Automatic monitoring of battery life. With labelling field 61 x 20 mm.
Including fixing plate for mounting on smooth walls or Protection class (Device): IP 20
on switch boxes. Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
Control element: rocker switch left/right
Display elements: LED to indicate the transmission studio white 1572 CN-84 2CKA001582A0348 10
Rated voltage: 3 V- 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Protection class (Device): IP 20 2) Can also be used for Busch-axcent®, solo®, and carat®.
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm 11
Cover plate ) )
2
1
ivory white 6733-82-500 2CKA006730A0034 1/10 with red and neutral light panel and labelling field
studio white 6733-84-500 2CKA006730A0040 1/10 For Alarm Control Unit insert 1515 U-12.
For Busch-Alarm signal insert 1563 U-12.
1) Battery included in delivery.
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. For indication lamp insert 1564 U-1x.
With labelling field 61 x 61 mm.
Protection class (Device): IP 20
WaveLINE LED display ) Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
1
For status display of window handle positions: open = studio white 1573 CN-84 2CKA001582A0350 10
red, closed = green, tilted = yellow.
Direct onsite operation possible for switching / 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Can also be used for Busch-axcent®, solo®, and carat®.
dimming an electrical device depending on the flush-
mounted insert.
4 individual LED display channels. Cover plate ) )
1
2
Up to 8 WaveLine transmitters can be taught-in on each 6gang, illuminable, with labelling field
LED display channel. For signal panel insert 1566 U.
Up to 8 WaveLine transmitters can be taught-in on With labelling field 61 x 61 mm.
onsite operation. Protection class (Device): IP 20
After a power cut all LED-Display channels light in red. Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
The cyclic telegram repeat of the WaveLINE window
position sensor 6720-xxx sensor automatically updates studio white 1575 CN-84 2CKA001582A0353 10
the window open state. 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Status display for depleted WaveLINE transmitter 2) Can also be used for Busch-axcent®, solo®, and carat®.
battery.
Status display for faulty transmission link and defective
2
1
WaveLINE transmitter. Cover plate ) )
User-friendly start-up without PC / software. with labelling field
Printed labelling sheet with 8 different inlay sheets. For power supply insert 1518 U.
For WaveLINE window position sensor 6720-6x. For relay insert 1539 U.
For WaveLINE 6721-xx universal signalling unit. For signal generator insert 1561 U-....
For Busch-Watchdog 220 WaveLINE 6747 AGM. With labelling field 61 x 61 mm.
For Busch-Universal relay switch insert 6404 U. Protection class (Device): IP 20
For universal dimmer switch insert 6595 U. Dimensions: (L x W x D): 63.5 mm x 63.5 mm x 11.1 mm
Free-field range: approx. 100 m. studio white 1576 CN-84 2CKA001582A0355 10
Send/receive frequency: 868 MHz. 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Protection class (Device): IP 20 2) Can also be used for Busch-axcent®, solo®, and carat®.
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm
ivory white 6730-82 2CKA006730A0015 1
studio white 6730-84 2CKA006730A0017 1
2
grey metallic ) 6730-803 2CKA006730A0025 1
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Surface painted.
