11/170 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
solo®
Accessories Cover frames

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Extension of claws ) Cover frame ) 1
1
For the installation of flush-mounted SCHUKO® socket 1gang frame
outlets and also switches, push-buttons, etc. and deeply For vertical or horizontal installation.
installed flush-mounted boxes. Protection class (Device): IP 20
Protection class (Device): IP 20
2148 2CKA002148A0120 100 chrome 1721-80-500 2CKA001754A4535 10/100
1) Not suitable for types 2000/3 US, 2000/6/2 US, 2000/6/6 US-101 and double chrome gloss 1721-80G-500 2CKA001754A4538 10/100
socket outlets.
studio white 1721-84-500 2CKA001754A4536 10/100
1) Suitable for installation in trunking systems with 80 mm conduit.
Braille symbol
self-adhesive (transparent) for cover 2506-xxx
Protection class (Device): IP 20 Cover frame
2gang frame
For vertical or horizontal installation.
Protection class (Device): IP 20

light
2144 LI 2CKA001714A0295 10/1000 chrome 1722-80-500 2CKA001754A4537 10/100
chrome gloss 1722-80G 2CKA001754A4327 10
bell
studio white 1722-84-500 2CKA001754A4539 10/100
2144 KI 2CKA001714A0296 10/1000
key Cover frame
11
2144 TR 2CKA001714A0297 10/1000 3gang frame
For vertical or horizontal installation.
Protection class (Device): IP 20
Braille symbol
socket outlet
self-adhesive, transparent for SCHUKO® socket outlets
with hinged lid 20 EUK-xxx chrome 1723-80-500 2CKA001754A4540 10/100
Protection class (Device): IP 20 chrome gloss 1723-80G 2CKA001754A4328 10
studio white 1723-84-500 2CKA001754A4541 10/100
2144 ST 2CKA001714A0298 10/1000
Cover frame
DIN A 4 labelling sheet ) 1 4gang frame
plastic foil For vertical or horizontal installation.
Suitable for all to be labeled Busch-Jaeger devices. Protection class (Device): IP 20
For laser printer.
The text of the foil is printed via the Busch-Jeager
labeling service.
chrome 1724-80 2CKA001754A4107 1
translucent 1799/02 2CKA001799A0959 1 chrome gloss 1724-80G 2CKA001754A4329 1
transparent 1799/03 2CKA001799A0960 1 studio white 1724-84 2CKA001754A4112 1
1) 1 piece = 1 sheet.
Cover frame
RC suppressor 5gang frame
For protection against the damage or destruction of For vertical or horizontal installation.
electronic devices due to overvoltages. Protection class (Device): IP 20
For wiring network-interconnected inductivities (e.g..
relay, protection, fluorescent lamps, transformers, etc.).
Eliminates functional disturbances on electronic
devices, e.g. automatic circuit reclosure (clocking) of a chrome 1725-80 2CKA001754A4108 1
movement detector. chrome gloss 1725-80G 2CKA001754A4330 1
Dimensions: diameter 25 mm, length 35 mm, length of studio white 1725-84 2CKA001754A4113 1
the connecting cable approx. 100 mm.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
6899 2CKA006899A0231 10
