11/168 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
solo®
LED light WaveLINE control elements

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Info light unit ) ) 2 Wall-mounted transmitter WaveLINE ) )
1
Size of information field 43 x 43 mm. 1-channel
Long service life of the lighting element (LEDs). 1gang wall-mounted transmitter independent of mains
Homogeneous backlighting of the information field. power supply.
Colour temperature 6,500 K (cold white) With labelling field and labelling strip.
Power consumption: < 0.5 W For switching and dimming.
Rated voltage: 230 V~ For controlling blinds and light scenes.
Rated frequency: 50 Hz - 60 Hz 1 radio channel can be operated or up to 2 light scenes
Protection class (Device): IP 20 can be called up.
For flush-mounted WaveLINE actuators 6701-101, 6702,
2062 U 2CKA001511A0115 1/10
6703, 6704 and 6705-101.
1) Use relay inserts when switching through movement sensors or comfort switches. For LED display WaveLINE 6730-xxx.
2) For switching the LED flush mounted insert use switches without orientation light
only. Compatible with WaveLINE KNX gateway TP-RF 6770.
Send frequency: 868 MHz.
Free-field range: approx. 100 m.
2
Cover plate ) ) Power supply: lithium button cell battery Type CR2032.
1
As cover for flush-mounted info light. Battery service life: typically 5 years, therefore
For insert 2062 U. practically maintenance-free.
Size of information field 43 x 43 mm. Automatic monitoring of battery life.
Protection class (Device): IP 20 Including fixing plate for mounting on smooth walls or
on switch boxes.
Control element: rocker switch left/right
ivory white 1716-82 2CKA001731A1922 1 Display elements: LED to indicate the transmission
studio white 1716-84 2CKA001731A1923 1 Rated voltage: 3 V-
Protection class (Device): IP 20
grey metallic ) 1716-803 2CKA001731A1976 1
3
Temperature range (Device): -5 °C to 45 °C
1) Included with the cover are 46 different text labels and symbols. Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm
11
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
3) Surface painted. ivory white 6731-82-500 2CKA006730A0032 1/10
studio white 6731-84-500 2CKA006730A0038 1/10
Cover plate 1) Battery included in delivery.
for indication lamp 2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
For insert 2061/2661 U.
As cover for flush-mounted light signal. Wall-mounted transmitter WaveLINE ) )
2
1
Protection class (Device): IP 20 2-channel
2gang wall-mounted transmitter independent of mains
power supply.
ivory white 1756-82 2CKA001753A0090 10
With labelling field and labelling strip.
studio white 1756-84 2CKA001753A0092 10 For switching and dimming.
grey metallic ) 1756-803 2CKA001753A0088 10 For controlling blinds and light scenes.
1
2 radio channels can be operated or up to 4 light scenes
1) Surface painted.
can be called up.
For flush-mounted WaveLINE actuators 6701-101, 6702,
Cap 6703, 6704 and 6705-101.
for indication lamp For LED display WaveLINE 6730-xxx.
For indication lamps. Compatible with WaveLINE KNX gateway TP-RF 6770.
Protection class (Device): IP 20 Send frequency: 868 MHz.
Free-field range: approx. 100 m.
Power supply: lithium button cell battery Type CR2032.
Battery service life: typically 5 years, therefore
clear-transpar- 1565-11 2CKA001565A0167 10 practically maintenance-free.
ent Automatic monitoring of battery life.
Red 1565-12 2CKA001565A0175 10 Including fixing plate for mounting on smooth walls or
on switch boxes.
green 1565-13 2CKA001565A0183 10
Control element: rocker switch left/right
Display elements: LED to indicate the transmission
Rated voltage: 3 V-
Protection class (Device): IP 20
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm
ivory white 6732-82-500 2CKA006730A0033 1/10
studio white 6732-84-500 2CKA006730A0039 1/10
1) Battery included in delivery.
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
