11/236 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
future® linear
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Universal-Slave insert Busch-Comfort switch )
1
3 wire connection (neutral conductor required). complete set
For the extension of Busch-Comfort switch or Busch- Ready-to-install movement detector/push-button
Presence detector installations. For communication switch combination (set packaging).
with Universal relay insert 6440/01 U-500. Consisting of Busch-Comfort switch control element
For communication with Universal-e-contact insert 6815-84-101-500.
6440/04 U-500. For Busch-Comfort switch control Consisting of Busch-Universal relay switch insert
element 6815-...-101-500. 6440/01 U-500.
For Busch-Presence detector sensor 6813-…-102-500. Consisting of 1gang future® linear cover frames.
Rated voltage: 230 V~, +10 % / -10 % Control element: 2 controllers for setting the brightness
Rated frequency: 50 Hz - 60 Hz switching threshold and switch-off delay.
Control/Signal outputs: 1, electronic output, potential- Display elements: LED for status display.
bound. Rated voltage: 230 V~, +10 % / -10 %
Temperature range (Device): -5 °C to 45 °C Rated frequency: 50 Hz - 60 Hz
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm Outputs: 1x Normally open contact, potential-bound
Mounting depth: 31 mm Suitable for: 230 V~ LEDi
Rated power: 100 W/VA
6440/05 U-500 2CKA006400A0091 1
Suitable for: 230 V incandescent lamps/230 V halogen
lamps
1
2
Busch-Comfort switch control element ) ) Rated current: 10 AX
with neon lamp Rated power: 2300 W
Movement detector/push-button switch combination. Suitable for: Niedervolt Halogenlampen mit
Push switch function possible at all times. elektronischen Transformatoren.
For switching lighting systems that depend on Rated power: 2300 VA
brightness and movement. Extension of the detection Detection range: frontal: 5 m, lateral: 3 m, Mounting
range by means of master/slave combination. height: 1.1 m
Additional activation/deactivation possibility through Detection angle: 170 °
11
pushbutton input.
Adjustable operating mode: automatic mode, automatic Brightness limit value: 5 Lux - 500 Lux , Daytime
(motion-controlled) switch-on and switch-off. operation
Adjustable operating mode: semiatuomatic, manual Mounting height: 0.8 m - 1.2 m
switch-on, automatic (time and motion-controlled) Protection class (Sensor): IP 20
switch-off. Temperature range (Device): 0 °C to 35 °C
Adjustable operating mode: automatic switch-on, Dimensions: (L x W x D): 81 mm x 81 mm x 52 mm
manual switch-off. Mounting depth: 31 mm
With continuous light/continuous off function. DIN EN 60669-2-1
Adjustment elements on the rear. studio white 6816 UJ-84-500 2CKA006800A2859 1
Surveillance density: 9 sectors with 28 switching
segments. 1) The range specifications refer to an ambient temperature of 21 °C.
Switch-off delay: 1 to 10 min., adjustable.
For Busch-Universal relay switch insert 6440/01 U-500.
For Universal-e-contact insert 6440/04 U-500.
For Universal-Slave insert 6440/05 U-500.
Control element: 2 controllers for setting the brightness
switching threshold and switch-off delay.
Display elements: LED for status display.
Detection range: frontal: 5 m, lateral: 3 m, Mounting
height: 1.1 m
Detection angle: 170 °
Brightness limit value: 0.5 Lux - 500 Lux , Daytime
operation
Mounting height: 0.8 m - 1.2 m
Protection class (Sensor): IP 20
Temperature range (Device): 0 °C to 35 °C
Dimensions: (L x W x D): 63 mm x 63 mm x 28.3 mm
DIN EN 60669-2-1
future® linear
anthracite 6815-81-101-500 2CKA006800A2828 1
ivory white 6815-82-101-500 2CKA006800A2830 1
aluminium 6815-83-101-500 2CKA006800A2832 1
silver
studio white 6815-84-101-500 2CKA006800A2834 1
studio white 6815-884-101-500 2CKA006800A2838 1
matt )
3
3
black matt ) 6815-885-101-500 2CKA006800A2840 1
1) Please order the respective flush-mounted insert separately.
2) The range specifications refer to an ambient temperature of 21 °C.
3) Surface painted.
