future® linear
Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
Room thermostat, flush-mounted ) ) Cover plate
1
Change-over contact, setpoint indication, timer, for room thermostat
remote sensor For room thermostats 1094 U, 1097 U.
With change-over contact.
Easy adjustment using menu and text-based display.
4 switching times per day can be user-defined for each
day of the week.
With fixing claws. anthracite 1794-81 2CKA001710A3629 10
Automatic summer/wintertime switch-over ivory white 1794-82 2CKA001710A3543 10
Remote sensor cable length: 4 m. aluminium 1794-83 2CKA001710A3668 10
Sensor =NTC, 10 kilo-ohm at 25 degrees C. silver ) 1
Power reserve > 10 hours
To fit cover plate 6435-xxx. studio white 1794-84 2CKA001710A3544 10
Class of temperature controller 1 studio white, 1794-884 2CKA001710A3884 10
Contribution to space heating energy efficiency 1,0%. matt ) 1
Rated voltage: 230 V~ 1
Rated current: 16 A black matt ) 1794-885 2CKA001710A3907 10
Temperature range (Device): 10 °C to 50 °CEN 60730-2-9 1) Surface painted.
1098 UF-101 2CKA001032A0509 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, Cover plate
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall for room thermostat
or 3060 wallbox concrete) With sliding switch for nightly room temperature
2) Servo valves of "closed or open when de-energized“ design are required for the reduction.
controller. E.g. article no. 6164/10-101. to activate nighttime mode and reduction of room
temperature by 4K, for thermostats 1095 U, 1096 U and
1095 UF. 11
1
2
3
Room thermostat, flush-mounted ) ) )
Heating/cooling anthracite 1795-81 2CKA001710A3630 10
With separate connection (230 V~) for external ivory white 1795-82 2CKA001710A3568 10
switchover between heating or cooling.
Switch contact opens when the set temperature is aluminium 1795-83 2CKA001710A3669 10
reached. silver ) 1
With fixing claws. studio white 1795-84 2CKA001710A3569 10
Nominal current: 10 A heating
Nominal current: 5 A cooling studio white, 1795-884 2CKA001710A3886 10
1
Class of temperature controller 1 matt )
Contribution to space heating energy efficiency 1,0%. black matt ) 1 1795-885 2CKA001710A3909 10
Rated voltage: 230 V~ 1) Surface painted.
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
Cover plate
1099 UHK 2CKA001032A0515 1/10
for room thermostat
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, For room thermostats 1094 UTA, 1097 UTA.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
anthracite 1794 TA-81 2CKA001710A3695 10
ivory white 1794 TA-82 2CKA001710A3696 10
Room thermostat, flush-mounted ) ) ) aluminium 1794 TA-83 2CKA001710A3697 10
2
3
1
Heating/cooling, sliding switch silver ) 1
With built-in sliding switch for switchover between
cooling or heating. studio white 1794 TA-84 2CKA001710A3698 10
Switch contact opens when the set temperature is studio white, 1794 TA-884 2CKA001710A3883 10
reached. matt ) 1
With fixing claws. 1
Nominal current: 10 A heating black matt ) 1794 TA-885 2CKA001710A3906 10
Nominal current: 5 A cooling 1) Surface painted.
Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
1099 UHKEA 2CKA001032A0516 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
