basic55®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Cinch-jacks Stereo loudspeaker connection box )
for communication adapter With screwless terminals (with screw-type terminals on
To link analogue audio devices like audio-receiver, the back).
amplifier and HiFi-sets. With 4 terminals.
Audio-band 20Hz - 20kHz. Cable cross-section max. 10 mm2.
Marked white: audio , channel left. Polarity is indicated by color.
With soldering tag. With claw.
Protection class (Device): IP 20 Protection class (Device): IP 20
alpine white 0263/04-500 2CKA000230A0451 1 white 0248/02-101 2CKA000230A0402 10/100
1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
Cinch-jacks
for communication adapter Stereo loudspeaker connection box )
1
To link analogue audio devices like audio-receiver, With screwless terminals (with screw-type terminals on
amplifier and HiFi-sets. the back).
Audio-band 20Hz - 20kHz. With 4 terminals.
Marked black: audio , channel left. Cable cross-section max. 10 mm2.
With soldering tag. Polarity is indicated by color.
Protection class (Device): IP 20 With claw.
black 0263/05-500 2CKA000230A0452 1 Protection class (Device): IP 20
alpine white 0248/04-101-500 2CKA000230A0464 10/100
Cinch-jacks 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
for communication adapter
To link analogue audio devices like audio-receiver, Stereo loudspeaker connection box )
1
amplifier and HiFi-sets. With screwless terminals (with screw-type terminals on 11
Audio-band 20Hz - 20kHz. the back).
Marked red: audio , channel left. With 4 terminals.
With soldering tag. Cable cross-section max. 10 mm2.
Protection class (Device): IP 20
Polarity is indicated by color.
Red 0263/06-500 2CKA000230A0453 1 With claw.
Protection class (Device): IP 20
Cinch-jacks anthracite 0248/05-101 2CKA000230A0404 10/100
for communication adapter 1) Suitable for cover telephone unit 1766-xxx and 2539-21x.
For connecting analogue video devices, such as
DVD players, hard disc recorders, video recorders or
receivers. Cover plate
Marked yellow: audio , channel left. For Busch-DigitalRadio 8215 U/8216 U.
With soldering tag. For Busch-Radio iNet.
Protection class (Device): IP 20 For Busch-Radio BTconnect 8217 U.
yellow 0263/07-500 2CKA000230A0454 1
white 8252-92-507 2CKA008200A0166 10
Communication adapter
for Mini-jacks 3,5mm. champagne 8252-93-507 2CKA008200A0157 10
Suitable for telephone connection unit cover plates alpine white 8252-94-507 2CKA008200A0169 10
2539-21x and 1766-xxx. château-black 8252-95-507 2CKA008200A0160 10
To support 1 or 2 jacks.
For trunk systems, flush-mounted wall boxes and chalet-white 8252-96-507 2CKA008200A0163 10
underfloor systems.
Without cover plate. Cover plate
Without claws. For loudspeaker insert 8223 U.
Protection class (Device): IP 20
white 0264/11-500 2CKA000230A0458 1
grey 0264/13-500 2CKA000230A0460 1
alpine white 0264/12-500 2CKA000230A0459 1
white 8253-92-507 2CKA008200A0167 1/10
Mini-jack 3,5 mm champagne 8253-93-507 2CKA008200A0158 1/10
for communication adapter alpine white 8253-94-507 2CKA008200A0170 1/10
For the connection of mobile terminal devices such as château-black 8253-95-507 2CKA008200A0161 1/10
MP3 player (stereo), mobile telephone and smartphones.
Audio-band 20Hz - 20kHz. chalet-white 8253-96-507 2CKA008200A0164 1/10
With soldering tag.
Protection class (Device): IP 20
chrome gloss 0264-500 2CKA000230A0462 1
