11/302 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

HDMI connection unit ) USB connection unit ) 1
1
with screw-type terminals and strain relief with screw-type terminals and strain relief
Suitable for telephone connection unit cover plates Suitable for telephone connection unit cover plates
2539-21x and 1766-xxx. 2539-21x and 1766-xxx.
To link high-definition digital audio and video data from To link mobile devices like e.g. printer, scanner, USB-
e.g. SAT-receiver, DVD-/Blue-Ray-player to plasma-type, sticks or digital cameras etc.
LCD- or-LED-TVs/screens. USB-type A, USB 2.0 compatible.
HDMI-type A, 3D-compatible. For 5-wire USB- cables via srew-type terminals.
Fully HD ready (1920 x 1080 pixel). For trunk systems, flush-mounted wall boxes and
For 20-wire HDMI-cables via srew-type terminals. underfloor systems.
For trunk systems, flush-mounted wall boxes and For easy installation and to follow the valid bending
underfloor systems. radii the "Kaiser- electronic-wall-box" type 1068-02 or
For easy installation and to follow the valid bending 9062-74 is recommended.
radii the "Kaiser- electronic-wall-box" type 1068-02 or Without cover plate.
9062-74 is recommended. Without claws.
Without cover plate. Protection class (Device): IP 20
Without claws. Mounting depth: 34 mm
Protection class (Device): IP 20 white 0261/11-500 2CKA000230A0418 1
Mounting depth: 34 mm
grey 0261/13-500 2CKA000230A0420 1
white 0261/31-500 2CKA000230A0430 1
alpine white 0261/12-500 2CKA000230A0419 1
grey 0261/33-500 2CKA000230A0432 1
1) Please follow the recommendations of the cable and device producers for the max.
alpine white 0261/32-500 2CKA000230A0431 1 USB cable lengths.
1) Please follow the recommendations of the cable and device producers for the max.
HDMI cable lengths.
Communication adapter
for BNC-F Duct-jacks
11
VGA connection unit ) Suitable for telephone connection unit cover plates
1
with screw-type terminals and strain relief 2539-21x and 1766-xxx.
Suitable for telephone connection unit cover plates To support 1 or 2 jacks.
2539-21x and 1766-xxx. For trunk systems, flush-mounted wall boxes and
To link analogue video data between PCs and laptops to underfloor systems.
monitors or digital projectors etc. Without cover plate.
VGA-type: D-type, 15-pole. Without claws.
Fully HD ready (1920 x 1080 pixel). Protection class (Device): IP 20
For 15-wire VGA-cables via srew-type terminals. white 0262/11-500 2CKA000230A0436 1
For trunk systems, flush-mounted wall boxes and
underfloor systems. grey 0262/13-500 2CKA000230A0438 1
For easy installation and to follow the valid bending alpine white 0262/12-500 2CKA000230A0437 1
radii the "Kaiser- electronic-wall-box" type 1068-02 or
9062-74 is recommended.
Without cover plate. F duct-jack
Without claws. for communication adapter
Protection class (Device): IP 20 For connection of antenna cables e.g.. for TVs with
Mounting depth: 34 mm integrated TV-tuner and satellite receiver.
With screw-type terminals.
white 0261/21-500 2CKA000230A0424 1
For trunk systems, flush-mounted wall boxes and
grey 0261/23-500 2CKA000230A0426 1 underfloor systems.
alpine white 0261/22-500 2CKA000230A0425 1 Protection class (Device): IP 20
1) Please follow the recommendations of the cable and device producers for the max. metal clad 0262-500 2CKA000230A0440 1
VGA cable lengths.
Communication adapter
for Cinch-jacks
Suitable for telephone connection unit cover plates
2539-21x and 1766-xxx.
To support 1 or 2 jacks.
For trunk systems, flush-mounted wall boxes and
underfloor systems.
Without cover plate.
Without claws.
Protection class (Device): IP 20
white 0263/11-500 2CKA000230A0444 1
grey 0263/13-500 2CKA000230A0446 1
alpine white 0263/12-500 2CKA000230A0445 1
