11/304 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Multimedia / communication adapters Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover plate Room thermostat, flush-mounted ) ) ) 3
1
2
For telephone connection unit. Switch contact opens when the set temperature is
For USB, VGA, HDMI inserts and communication reached.
adapter. With fixing claws.
USB power adapter insert 6472 U. Separate terminal to activate nighttime mode and
For loudspeaker connection box. reduction of room temperature by 4K.
Suitable for part number 0248/0x-101. Class of temperature controller 1
For data modules. Contribution to space heating energy efficiency 1,0%.
Suitable for Art. No. 0219/12 and 0219/13. Rated voltage: 230 V~
For modular outlets with 90° RJ45 outlet from Rated current: 10 A
Telegärtner (type MJ and WE). Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
white 2539-92-507 2CKA001724A4279 10
champagne 2539-93-507 2CKA001724A4312 10 1094 U-500 2CKA001032A0512 1/10
alpine white 2539-94-507 2CKA001724A4275 10/100 Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
château-black 2539-95-507 2CKA001724A4315 10
2gang product 2gang combination with adapter plate
chalet-white 2539-96-507 2CKA001724A4318 10 combinations: APBS in Dual Box only.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Cover plate for Busch-powerDock Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
For Busch-powerDock charging cradle. 2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
Room thermostat, flush-mounted ) ) ) 3
2
1
white 6477-92-507 2CKA006400A0050 10 Slide switch
11
alpine white 6477-94-507 2CKA006400A0052 10 With built-in slide switch and control lamp for nightly
reduction of 4 K.
champagne ) 1 6477-93-507 2CKA006400A0053 10
Switch contact opens when the set temperature is
château-black 6477-95-507 2CKA006400A0054 10 reached.
chalet-white 6477-96-507 2CKA006400A0055 10 With fixing claws.
Separate terminal to activate nighttime mode and
1) Surface painted.
reduction of room temperature by 4K.
Class of temperature controller 1
Cover plate Contribution to space heating energy efficiency 1,0%.
For USB charging station 6474 U. Rated voltage: 230 V~
With protective function against lateral slipping of the Rated current: 10 A
mobile telephone. Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
Suitable for devices with a maximum thickness of 18 British Standard EN 60669-2-1
mm. 1095 U-500 2CKA001032A0514 1/10
With frontal mounting option of connecting cable.
Mounting 35 mm deep flush 1gang
white 6478-92-507 2CKA006400A0010 1 boxes: or Dual Box 3070-2/35 BSDB.
alpine white 6478-94-507 2CKA006400A0011 1 2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Cover plate
For Busch Bluetooth receiver 8219 U. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
white 8255-92-507 2CKA008200A0205 1
champagne ) 1 8255-93-507 2CKA008200A0208 1
alpine white 8255-94-507 2CKA008200A0207 1
château-black 8255-95-507 2CKA008200A0209 1
chalet-white 8255-96-507 2CKA008200A0210 1
1) Surface painted.
