11/348 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
Dimmer actuator Heating & fan coil actuators

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Dimming actuator 4-gang Heating actuator 6-gang
Multi-channel universal dimming actuator for controlling For controlling thermoelectric actuating drives in
LEDs, incandescent lamps, 230 V halogen lamps, low- heating/cooling systems.
voltage halogen lamps with conventional or electronic The outputs are protected against short-circuit and
transformers, and dimmable energy-saving halogen lamps. overload.
For dimmable Retrofit-LEDs (LEDi). The bus can be connected via enclosed terminal block.
Increasing the max. load via channel bridging possible. Programming only with bus voltage applied via the web
The outputs can be switched parallel in any combination. interface of the System Access Point.
Outputs automatically recognize the connected load. Power dissipation: 2 W
In addition, the operating mode can be selected manually. Bus voltage: 24 V
Status indication of the channels via LED. Outputs: 6
The bus can be connected via enclosed terminal block. Suitable for: resistive
Display elements: outputs status indication via LED. Rated current: 160 mA
Programming only with bus voltage applied via the web Protection class (device): IP20
interface of the System Access Point. Temperature range (device): -5 °C to 45 °C.
Rated voltage: 230 V~; 50/60 Hz Dimensions: (L x W x D): 90 mm x 72 mm x 64 mm.
Bus voltage: 24 V Module width (DIN-rail): 4 MW.
Outputs: 4 dimming channel
Suitable for: 230 V incandescent lamps and low-voltage HA-M-0.6.1 2CDG510008R0011 1
halogen lamps with conventional transformers or
electronic transformer.
Rated power: 10 - 315 W/VA Heating actuator 12-gang
Suitable for: LEDi and energy-saving bulbs; typical For controlling thermoelectric actuating drives in
Rated power: 2 - 80 W/VA heating/cooling systems.
Protection class (device): IP20 The outputs are protected against short-circuit and
Temperature range (device): -5 °C to 45 °C overload.
Dimensions: (L x W x D): 90 mm x 144 mm x 64 mm The bus can be connected via enclosed terminal block.
Module width (DIN-rail): 8 MW. Programming only with bus voltage applied via the web
11
interface of the System Access Point.
DA-M-0.4.2 2CKA006220A0395 1 Power dissipation: 4 W
Bus voltage: 24 V
Outputs: 12
Blind actuator Suitable for: ohmic
Rated current: 160 mA
Protection class (device): IP20
Product Article-No. Order-No. Pack/Qty
Temperature range (device): -5 °C to 45 °C
Dimensions: (L x W x D): 90 mm x 144 mm x 64 mm.
Blind actuator 4-gang
For controlling 4 independent blind or roller shutter drives. Module width: 8 MW.
The outputs are inversely blocked.
The bus can be connected via enclosed terminal block. HA-M-0.12.1 2CDG510009R0011 1
Programming only with bus voltage applied via the web
interface of the System Access Point. Fan coil actuator
Power dissipation: 2 W For controlling blower convectors. Supports 2-pipe and
Bus voltage: 24 V 4-pipe system for heating and cooling. The fan speed
Outputs: 4 levels can be switched using a changeover or step switch
Suitable for: AC3 (Output voltage: 230 V~) function.
Rated current: 6 A, cos φ0.45 Three contacts for switching a three-stage fan.
Protection class (device): IP20 Two contacts for activating the heating and cooling valves.
Temperature range (device): -5 °C to 45 °C Supports 24V and 230V valves.
Dimensions: (L x W x D): 90 mm x 72 mm x 64 mm With two binary inputs for connecting dew-point and
Module width (DIN-rail): 4 MW. condensation contacts.
The scanning voltage is provided by the device.
BA-M-0.4.1 2CDG510011R0011 1 The bus connection is provided via the enclosed bus terminal.
Programming only with bus voltage applied via the web
interface of the System Access Point.
Bus voltage: 24 V
Inputs: 2
Polling voltage: 10 V-
Outputs: 3 Normally Open contact, potential free
Suitable for: AC3 (Output voltage: 230 V~)
Rated current: 6 A
Protection class (device): IP20
Temperature range (device): -5 °C to 45 °C.
Dimensions: (L x W x D): 90 mm x 108 mm x 64.5 mm.
Module width (DIN-rail): 6 MW.
FCA-M-2.3.1 2CDG510010R0011 1
