11/346 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
System Access Point Weather station

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

System Access Point - Wireless Weather station
For commissioning and remote control of the For recording and transmitting of brightness,
ABB-free@home® system. temperature, wind speed and rain.
With integrated free@home wireless antenna. Weather data can be linked with actuators to
With integrated free@home bus connection. automatically control functions.
Allows the execution of astro and time programs. Weather data can be visualized in the free@home web
Commissioning and remote control is executed via the interface and the free@home app.
web interface or app. Wind speed measuring range 2 - 30 m/s
No additional commissioning software is required. The bus can be connected via enclosed terminal block.
Easy commissioning with WLAN ad-hoc mode. Rated voltage: 110 V~ - 230 V~; 50/60 Hz.
WLAN modes switchable via local operation. Bus voltage: 24 V-
Connection to the home network via WLAN client mode Inputs: 4
or via CAT cable. Temperature range (sensor):
The bus connection is provided via the enclosed bus Brightness limit value: 1 lux - 100000 lux
terminal. Dimensions: (L x W x D): 108 mm x 121 mm x 227 mm
Display elements: LED for status display. Protection class (device): IP44
Rated voltage: 230 V~; 50/60 Hz. Temperature range (device): -20 °C to 55 °C
Bus voltage: 24 V.
Dimensions: (L x W x D): 110 mm x 170 mm x 31 mm WS-1 2CKA006220A0390 1
Programming via the web interface of the System Access
Point.
Protection class (device): IP20 Power supply
Temperature range (device): -5 °C to 45 °C
SAP-S-2 2CKA006200A0105 1 Product Article-No. Order-No. Pack/Qty
Power supply
External antenna - Wireless Power supply with integrated choke.
11
For use with System Access Point SAP-S-2 and Fast diagnosis due to LED display for operational
SAP-S-127.2. readiness and errors.
Feed the free@home wireless signal to the outside The bus can be connected via enclosed terminal block.
when the internal antenna of the System Access Point is Display elements: operational load/overload LED
shielded due to structural conditions. Rated voltage: 127 V~ - 230 V~, +10 % / -15 %; 50/60Hz
With magnetic base. Secondary: 30 V, +2 V / --2 V
Cable length: 1.5 m Outputs: 1
Rated current: 640 mA
SAP-1-WL 2CKA006200A0100 1 Protection class (device): IP20
Temperature range (device): -5 °C to 45 °C
Dimensions: (L x W x D): 90 mm x 72 mm x 64 mm
Module width (DIN-rail): 4 MW

PS-M-64.1.1 2CDG510001R0011 1
