Sky Niessen
Binary inputs Switch actuators

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Binary input 2-gang Binary input 8-gang / switch actuator 8-gang
Conventional push-buttons or auxiliary contacts can be Combination device with 8 binary inputs and 8 switch
connected to 2 channels. The information of the contact actuators.
scanning can be used for activating ABB-free@home® Conventional push-buttons or auxiliary contacts can be
actuators or for recording status information. The connected to 8 channels. The information of the contact
contact polling voltage is made available from the binary scanning can be used for activating ABB-free@home®
input itself. Extension of the connecting cables possible actuators or for recording status information.
by a maximum of 10 m. The contact polling voltage is made available by the
Flush-mounted device for installation in a 60 mm device device itself.
box or distribution box. Maximum cable length at a cable cross-section of
The bus can be connected via enclosed terminal block. 1.5 mm² < 100 m
Programming only with bus voltage applied via the web For switching 8 independent 230 V~ loads.
interface of the System Access Point. No additional commissioning software is required.
Bus voltage: 24 V Programming only with bus voltage applied via the web
Inputs: 2 interface of the System Access Point.
Polling voltage: 20 V- Bus voltage: 24 V
Protection class (device): IP20 Inputs: 8
Temperature range (device): -5 °C to 45 °C Polling voltage: 35 V-
Dimensions: (L x W x D): 39 mm x 40 mm x 12 mm. Outputs: 8 Normally Open contact, potential free
Suitable for: AC1 (Output voltage: 230 V~)
BI-F-2.0.1 2CDG510002R0011 1 Rated current: 6 A, cos ϕ 0.8
Suitable for: AC3 (Output voltage: 230 V~)
Rated current: 6 A, cos ϕ 0.45
Binary input 4-gang Protection class (device): IP20
Conventional push-buttons or auxiliary contacts can Temperature range (device): -5 °C to 45 °C
be connected to 4 channels. The information of the Dimensions: (L x W x D): 90 mm x 144 mm x 64.5 mm
contact scanning can be used for activating ABB-free@ Module width (DIN-rail): 8 MW.
home® actuators or for recording status information. The 11
contact polling voltage is made available from the binary
input itself. Extension of the connecting cables possible SA-M-8.8.1 2CDG510007R0011 1
by a maximum of 10 m.
Flush-mounted device for installation in a 60 mm device
box or distribution box. Switch actuator 4-gang
The bus can be connected via enclosed terminal block. For switching 4 independent 127 V~/230 V~ loads.
Programming only with bus voltage applied via the web Each contact has a manual operation function
interface of the System Access Point. independent of auxiliary voltage for additionally
Bus voltage: 24 V displaying the contact setting.
Inputs: 4 The bus can be connected via enclosed terminal block.
Polling voltage: 20 V- Control element: relay control element.
Protection class (device): IP20 Display elements: relay control element.
Temperature range (device): -5 °C to 45 °C Programming only with bus voltage applied via the web
Dimensions: (L x W x D): 39 mm x 40 mm x 12 mm interface of the System Access Point.
Power dissipation: 4 W
Bus voltage: 24 V
BI-F-4.0.1 2CDG510003R0011 1
Outputs: 4
Suitable for: AC1 (Output voltage: 230 V~)
Binary input 4-gang Rated current: 16 A, cos ϕ 0.8
The device detects AC/DC signals of 10 - 230 V via 4 Suitable for: AC3
channels. The information of the signal evaluation can be Rated current: 8 A, cos ϕ 0.45
used for controlling ABB-free@home® actuators or for Protection class (device): IP20
recording status information. Temperature range (device): -5 °C to 45 °C
The bus can be connected via enclosed terminal block. Dimensions: (L x W x D): 90 mm x 72 mm x 64 mm
Programming only with bus voltage applied via the web Module width (DIN-rail): 4 MW.
interface of the System Access Point.
Bus voltage: 24 V SA-M-0.4.1 2CDG510006R0011 1
Inputs: 4
Protection class (device): IP20
Temperature range (device): -5 °C to 45 °C
Dimensions: (L x W x D): 90 mm x 36 mm x 64 mm
Module width DIN-rail): 2 MW
BI-M-4.0.1 2CDG510004R0011 1
