11/350 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen - KNX - Building automation
Sensor

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

KNX Push-button coupler - 2-gang with bus coupler KNX RTC with 5-gang universal input
With integrated temperature sensor. Control element with room thermostat function for
Support of KNX functions through innovative colour triggering the heating, ventilation and fan-coil actuators.
concept (yellow=lighting, blue=blind, orange=RTC, With universal input with:
- max. of 5 binary inputs.
magenta=scene and white=neutral/no function - 4 binary inputs and 1 analogue input for activating
assigned) or standard illumination red/green. sensors with external power supply 1-10 V/0-10 V
With middle position. - 2 binary inputs and 1 analogue input for activating
The bus can be connected via enclosed terminal block. sensors with external power supply 1-10 V/0-10 V and an
Control element: switch contacts top/bottom. external temperature sensor PT1000 / T6226.
With display of set-value temperature.
Display elements: 2 LED per rocker via separate Master/slave configuration.
communication object for status (Red/ Green/ OFF) or With base-load operation.
orientation light. The bus can be connected via enclosed terminal block.
Connections: KNX-line - bus connection terminal. Class of temperature controller 1.
Rated voltage: 24 V-, +5 V / -5 V. Contribution to space heating energy efficiency 1,0%.
Control element: switch contacts.
Temperature range device: -5 °C to 45 °C. Display elements: LCD showing operation mode and
To be installed with SR-1-85, SRL-1-85, SRD-1-85, temperature.
SRB-1-85 and SRS-1-85 cover plates. Connections: KNX-line - bus connection terminal.
Rated voltage / current: 24 V- / 5 mA.
Inputs: 5. Polling voltage: binary inputs, presence and/or
6108/06-500 2CKA006133A0221 1 window contact.
Control/Signal outputs: 1, 0-10 V (passive).
Temperature range device: -5 °C to 45 °C.
KNX Push-button coupler - 4-gang with bus coupler Tobe installed with CP-CO-85 cover plates.
With integrated temperature sensor.
Support of KNX functions through innovative colour 6109/18-500 2CKA006134A0315 1
concept (yellow=lighting, blue=blind, orange=RTC,
magenta=scene and white=neutral/no function
assigned) or standard illumination red/green. KNX RTC with CO₂/moisture sensor
With middle position. Control element with room temperature controller
11
The bus can be connected via enclosed terminal block. function and CO₂/moisture/air pressure sensor.
For activating heating, ventilation and fan coil actuators.
Control element: switch contacts top/bottom. With universal input with:
Display elements: 2 LED per rocker via separate - max. of 5 binary inputs.
communication object for status (Red/ Green/ OFF) or - 4 binary inputs and 1 analogue input for activating
orientation light. sensors with external power supply 1-10 V/0-10 V.
Connections: KNX-line - bus connection terminal. - 2 binary inputs and 1 analogue input for activating
sensors with external power supply 1-10 V/0-10 V and an
Rated voltage: 24 V-, +5 V / -5 V. external temperature sensor PT1000 / T6226.
Temperature range device: -5 °C to 45 °C. With display of set-value temperature.
To be installed with SR-2-85, SRL-2-L-85 SRL-2-R-85, SRD- Master/slave configuration.
2-L-85, SRD-2-R-85, SRB-2-85 SRS-2-L-85 and SRS-2-R-85 With base-load operation.
The bus can be connected via enclosed terminal block.
cover plates. Class of temperature controller 1.
Contribution to space heating energy efficiency 1,0%.
6108/07-500 2CKA006133A0223 1 Control element: switch contacts.
Display elements: LCD showing operation mode and
temperature.
KNX Room thermostat with display Connections: KNX-line - bus connection terminal.
Control element with room thermostat function for Rated voltage / current: 24 V- / 5 mA.
Inputs: 5. Polling voltage: binary inputs, presence and/or
triggering the heating, ventilation and fan-coil actuators. window contact.
For controlling commercially available valve drives. Control/Signal outputs: 1, 0-10 V (passive).
With display of set-value temperature. Temperature range device: -5 °C to 45 °C.
Master/slave configuration.
With base-load operation.
The bus can be connected via enclosed terminal block.
Class of temperature controller 1 6109/28-500 2CKA006134A0317 1
Contribution to space heating energy efficiency 1,0%.
Control element: switch contacts.
Display elements: LCD showing operation mode and KNX 180° motion sensor
temperature. Movement detector with up to 4 channels.
Connections: KNX-line - bus connection terminal. Detection range: frontal: 6 m, lateral: 6 m.
Rated voltage / current: 24 V- / 5 mA. Brightness limit value: 5 lux - 150 lux.
Temperature range device: -5 °C to 45 °C. Detection angle: 180°.
To be installed with CP-RTC-85 cover plates for RTC or Position for installation: vertical.
CP-RTC-FC-85 cover plates for fan coil control. Mounting height: 1.1 m.
Temperature range (device): -5 °C to 45 °C.
To be installed with CP-MD-85 cover plates (mounting
6108/18-500 2CKA006134A0319 1 grid without claws included).
6122/98-509 2CKA006132A0307 1
