11/364 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
Light controls - Rotatory dimmers Buzzer / Door bell

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Universal rotatory/push dimmer Buzzer
Rated voltage: 230 Vac / 50 Hz. Rated voltage: 230 Vac / 50 Hz.
Min. power: 60 W / VA. Rated power: 8 VA.
Max. power: Adjustable tone.
- Incandescent: 500 W. Acoustic power at 1 meter with cover plate: 75 dB.
- Halogen lamp with electronic transformer: 500 VA. Without fixing claws.
- Halogen lamp with ferromagnetic transformer: 400 VA. Cover plate code: 8629.
2 wire connection.
Optional: auxiliary control with 8104.X push-buttons. 8119 2CLA811900A1001 10
Indicator LED lamp included.
Operating temperature: 0 - 30º C.
Included: Electronic door bell with 4 melodies
- Cover plate with chrome ring. Rated voltage: 110 - 250 Vac.
- Mounting grid without claws. 4 melodies available.
Acoustic power at 1 meter with cover plate: 72 dB.
Chrome 8660 CR 2CLA866000A1401 1 Without fixing claws.
Cover plate code: 8629.
Black Glass 8660 CN 2CLA866000A1501 1
8124.2 2CLA812420A1001 1
LED rotatory/push dimmer
Rated voltage: 230 Vac ± 10%. Cover plate for buzzer/door bell
Frequency: 50 Hz (Nominal power: 250 W/VA) / 60 Hz Cover plate for buzzer / door bell code: 8119 & 8124.2.
(Nominal power: 200 W/VA).
Power (min./max load):
- LEDi: 2 / 100 W/VA (max. 10 lamps).
- Dimmable energy saving lamps: 2 / 100 W/VA (max. 10
lamps).
- LV LEDi with transformer (only type L or LC): Chrome 8629 CR 2CLA862900A1401 5
11
4 / 100 W / VA (max. 10 lamps). Black Glass 8629 CN 2CLA862900A1501 5
- Incandescent lamps: 10 / 250 W / VA.
- Halogen lamps: 10 / 250 W / VA.
- LV halogen with transformer (only type L or LC): Blank covers / Cable outlets
10 / 250 W/VA (max. 10 lamps).
2 wire connection. Product Article-No. Order-No. Pack/Qty
Optional: auxiliary on/off with 2-way switch 8102.
Indicator LED lamp included. Blank cover plate
Back-up fuse: Electronic. Included: mounting grid and cover plate.
Overload protection: Electronic. Without fixing claws.
Ambient temperature: 0° C to +35° C.
Included:
- Cover plate with chromes ring.
- Mounting grid without claws.
Chrome 8600 CR 2CLA860000A1401 2
Chrome 8660.2 CR 2CLA866020A1401 1 Black Glass 8600 CN 2CLA860000A1501 2
Black Glass 8660.2 CN 2CLA866020A1501 1
Cable outlet
1-10V rotatory dimmer 3 connection screw terminals up to 2,5 mm2.
Rated voltage: 127 - 230 Vac / 50 - 60 Hz. Cable tie included.
Dimmable electronic ballast/driver with 1-10V control Included: fixing claws.
input. Cover plate code: 8607.
Max. power:
- 230 Vac: 700 VA. 8107 2CLA810700A1001 10
- 127 Vac: 350 VA.
Max. 6 ballasts per device.
Indicator LED lamp included. Cover plate for cable outlet
Included: Cover plate for cable outlet code: 8107.
- Cover plate with chrome ring.
- Mounting grid without claws.
Chrome 8660.9 CR 2CLA866090A1401 1
Black Glass 8660.9 CN 2CLA866090A1501 1 Chrome 8607 CR 2CLA860700A1401 5
Black Glass 8607 CN 2CLA860700A1501 5
