11/400 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Impressivo
ABB-free@home

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Dimming actuator 4gang Movement detector
Multi-channel universal dimming actuator for For automatic switching of ABB-free@home® actuators
controlling LEDs, incandescent lamps, 230 V halogen dependent on movement and brightness.
lamps, low-voltage halogen lamps with conventional or
electronic transformers, and dimmable energy-saving
halogen lamps. For dimmable retrofit LED lamps (LEDi).
Increasing the maximum load via channel bridging
possible. The outputs can be switched parallel in any white MD-F-1.0.1-84 2TKA00002773 1/10
combination. Outputs automatically recognise the anthracite MD-F-1.0.1-81 2TKA00002771 1/10
connected load. In addition, the operating mode can be aluminium MD-F-1.0.1-83 2TKA00002772 1/10
selected manually. Status indication of the channels
via LED.
Movement detector/switch actuator
Universal dimmer 4gang For automatic switching of ABB-free@home® actuators
DA-M-0.4.2 2TKA00002715 1 dependent on movement and brightness.
Compensator With integrated switch actuator. Switching function
6596 2TKA00002992 1 is available also without prior programming
(pre-configured).
Dim actuator sensor white MSA-F-1.1.1-84 2TKA00002805 1/10
For dimming 230 V~ loads. With integrated universal anthracite MSA-F-1.1.1-81 2TKA00002803 1/10
dimming actuator for controlling different lamps. aluminium MSA-F-1.1.1-83 2TKA00002804 1/10
The dimming function is available also without prior
programming (pre-configured).

Dimmer 1/1-gang
SDA-F-1.1.1 2TKA00002800 1/10
11
Dimmer 1/1-gang WL
SDA-F-1.1.1-WL 1/10
Rocker 1-gang
white SR-1-84 2TKA00002776 1/10
anthracite SR-1-81 2TKA00002774 1/10
aluminium SR-1-83 2TKA00002775 1/10
Compensator
6596 2TKA00002992 1
Dimmer 2/1-gang
SDA-F-2.1.1 2TKA00002801 1/10
Dimmer 2/1-gang WL
SDA-F-2.1.1-WL 1/10
Rocker 2-gang left/right
white SR-2-84 2TKA00002779 1/10
anthracite SR-2-81 2TKA00002777 1/10
aluminium SR-2-83 2TKA00002778 1/10
