11/475

—
Zenit
Flush mounting boxes Frames for metallic and plastic profiles

Gangs Modules Article-No. Order-No. Pack/Qty Gangs Modules Article-No. Order-No. Pack/Qty

European type box - Bricks and cement Frame for metallic and plastic profiles
Installation box for walls built with bricks or Frames suitable to be installed in reduced
cement. dimensions surfaces as plastic and metallic profiles
Distance between screws: 60 mm or screens.
Suitable for mounting plates code: N2271.9,
N2271.9G & N2272.9. For 1 module devices.
Allows the input of 2 tubes per each side. Size (width x height): 32 x 68 mm.
Linkable for multigang frames. Shaft size (width x height): 26 x 50 mm.
Included: 2 screws to fix the mounting plate. The
screws can be placed in any of the 4 sides to 1-gang 1 module N2671 BL 2CLA267100N1101 10
facilitate the installation of the insert in vertical and
horizontal. 1-gang 1 module N2671 PL 2CLA267100N1301 10
1-gang 1 module N2671 AN 2CLA267100N1801 10
1-gang 2 modules 1099 2CLA009900A1001 50 1-gang 1 module N2671 CV 2CLA267100N1901 10

European type box - Drywall and partitions Frame for metallic and plastic profiles
Installation box for walls built with drywall or Frames suitable to be installed in reduced
partitions. dimensions surfaces as plastic and metallic profiles
Distance between screws: 60 mm or screens.
Suitable for mounting plates code: N2271.9, For 1 module devices.
N2271.9G & N2272.9.
Linkable for multigang frames. Size (width x height): 32 x 126 mm.
Included: 2 screws to fix the mounting plate. Shaft size (width x height): 26 x 108 mm.
Shaft diameter: 68 mm.
1-gang 2 modules 999 2CLA099909A1001 25

European type box - Drywall and partitions 2-gang 1+1 module N2671.2 BL 2CLA267120N1101 5 11
Double box suitable for 2-gang mounting plates. 2-gang 1+1 module N2671.2 PL 2CLA267120N1301 5
Installation box for walls built with drywall or
partitions. 2-gang 1+1 module N2671.2 AN 2CLA267120N1801 5
Distance between screws: 60 mm 2-gang 1+1 module N2671.2 CV 2CLA267120N1901 5
Suitable for mounting plates code: N2271.9,
N2271.9G & N2272.9.
Included: 4 screws to fix the mounting plate. Frame for metallic and plastic profiles
Shaft diameter: 68 mm. Frames suitable to be installed in reduced
Distance between centers: 71 mm. dimensions surfaces as plastic and metallic profiles
or screens.
For 1 and 2 module devices.
2-gang 2+2 modules 999.2 2CLA099920A1001 10 Size (width x height): 54 x 68 mm.
Shaft size (width x height): 49 x 50 mm.
3 module type box - Bricks and cement
Installation box for walls built with bricks or 1-gang 2 modules N2672 BL 2CLA267200N1101 6
cement.
Distance between screws: 83,5 mm. 1-gang 2 modules N2672 PL 2CLA267200N1301 6
Suitable for mounting plates code: N2371.9 & 1-gang 2 modules N2672 AN 2CLA267200N1801 6
N2373.9.
Included: 2 screws to fix the mounting plate. 1-gang 2 modules N2672 CV 2CLA267200N1901 6

1-gang 3 modules 499.3 2CLA049930A1001 25
DIN-rail mounting plate
4 module type box - Bricks and cement
Installation box for walls built with bricks or Adapter for DIN rail - 2M
cement. Adapter that facilitates the intallation of Zenit
Distance between screws: 107 mm devices up to 2 modules in switchboards on DIN
Suitable for mounting plates code: N2374.9.
Included: 2 screws to fix the mounting plate. rails.
RAL 9010.
Width: 53,5 mm.
1-gang 4 modules 1499.4 2CLA049940A1001 20
1-gang 2 modules N2692 BL 2CLA269200N1101 10
7 module type box - Bricks and cement
Installation box for walls built with bricks or
cement.
Distance between screws: 100 mm
Suitable for mounting plates code: N2777.9.
Without screws.
Included: 4 screws to fix the mounting plate.

1-gang 7 modules 1499.7 2CLA049970A1001 5
