11/476 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Zenit
IP20 surface mounting boxes IP40 surface mounting boxes

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Surface mounting box with frame - 2 modules Surface mounting box - IP40 - 2 modules
Surface mounting box for 1 and 2 module devices. Box for surface installation.
The box includes the clipping system to clasp inserts (no 1-gang - 2 modules.
mounting plate necessary). For 1 or 2 module devices.
Included: frame - 2 modules Size (height x width x depth): 80 x 65 x 55 mm.
Size (Width x Height x Depth): 64 x 70 x 47 mm. Color: gray - RAL 7035.
Pre-cut areas in the 4 sides for N2999 adapters. Protection degree: IP40 / IK06.
Incoming with multi-diameter cone for tubes/cables max.
White N2991.1 BL 2CLA299110N1101 10 Ø20.
The box includes the clipping system to clasp inserts (no
mounting plate, nor frame are necessary).
Surface mounting box - 2M
Surface mounting box for 1 and 2 module devices.
Suitable for 2 module mounting plates N2271.9. Gray N3291.1 2CLA329110N1101 10
Suitable for N2171 and N2271 frames.
Size (Width x Height x Depth): 86 x 86 x 44 mm. Surface mounting box - IP40 - 2+2 modules
Pre-cut areas in the 4 sides for N2999 adapters. Box for surface installation.
2-gang - 2+2 modules.
For 1 or 2 module devices.
White 8591 BL 2CLA859100N1101 6 Size (height x width x depth): 80 x 130 x 55 mm
Color: gray - RAL 7035.
Surface mounting box - 2+2M Protection degree: IP40 / IK06.
Surface mounting box for 1 and 2 module devices. Double incoming with multi-diameter cone for tubes/
Suitable for 2 module mounting plates N2271.9. cables max. Ø20.
Suitable for N2272 frames. The box includes the clipping system to clasp inserts (no
Size (Width x Height x Depth): 157 x 86 x 44 mm. mounting plate, nor frame are necessary).
Pre-cut areas in the 4 sides for N2999 adapters.
11
Gray N3292.1 2CLA329210N1101 10
White 8592 BL 2CLA859200N1101 5
Surface mounting box - IP40 - 2+2+2 modules
Surface mounting box - 2+2+2M Box for surface installation.
Surface mounting box for 1 and 2 module devices. 3-gang - 2+2+2 modules.
Suitable for 2 module mounting plates N2271.9. For 1 or 2 module devices.
Suitable for N2273 frames. Size (height x width x depth): 80 x 195 x 55 mm.
Size (Width x Height x Depth): 228 x 86 x 44 mm. Color: gray - RAL 7035.
Pre-cut areas in the 4 sides for N2999 adapters. Protection degree: IP40 / IK06.
Incoming with multi-diameter cone for tubes/cables max.
Ø20.
White 8593 BL 2CLA859300N1101 1
The box includes the clipping system to clasp inserts (no
mounting plate, nor frame are necessary).
Surface mounting box - 3M
Surface mounting box for 1, 2 or 3 module devices. Gray N3293.1 2CLA329310N1101 5
Suitable for 3 module mounting plates N2371.9 and N2373.9.
Suitable for N2471, N2472 and N2473 frames.
Size (Width x Height x Depth): 107 x 85 x 44 mm. Surface mounting box - IP40 - 3 modules
Pre-cut areas in the 4 sides for N2999 adapters. Box for surface installation.
1-gang - 3 modules.
For 1, 2 or 3 module devices.
White N2993 BL 2CLA299300N1101 10 Size (height x width x depth): 80 x 104 x 55 mm
Color: gray - RAL 7035.
Surface mounting box - 4M Protection degree: IP40 / IK06.
Surface mounting box for 1, 2 or 3 module devices. Incoming with multi-diameter cone for tubes/cables max.
Suitable for 4 module mounting plates N2374.9. Ø20.
Suitable for N2374 frames. The box includes the clipping system to clasp inserts (no
Size (Width x Height x Depth): 139 x 85 x 44 mm. mounting plate, nor frame are necessary).
Pre-cut areas in the 4 sides for N2999 adapters.
Gray N3391.1 2CLA339110N1101 10
White N2994 BL 2CLA299400N1101 5

Adapter for tubes/pipes
Adapter for tubes of Ø16, Ø20, Ø25.
Suitable for surface mounting boxes code:
N2991.1, 8591, 8592, 8593, N2993 and N2994.

White N2999 BL 2CLA299900N1101 10
