Zenit
IP55 flush mounting kits IP55 flush mounting frames

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Kit IP55 2-way switch - flush mounted Flush mounting frames - IP55 - 2 modules
Kit with: Frames for IP55 flush mounted installations.
- N3271 BL: IP55 frame for flush mounting - 1-gang - 2 1-gang - 2 modules.
modules. For 1 or 2 module devices.
- N2202 BL: 1-gang, 2-way / 127 - 250 Vac / 16 AX. Size (height x width): 90 x 90 mm.
- 1-gang, 2 module mounting plate. Included: one 1-gang, 2 module mounting plate.
Protection degree: IP55 (with lid closed). Protection degree: IP55 (with lid closed).
Color: white. Opening angle of the lid: 120°.
Opening angle of the lid: 120°. The lid allows operating the switch in closed position.
The lid allows operating the switch in closed position. Suitable for 60mm screw distance boxes.

White N3002 2CLA300200N1101 10 White N3271 BL 2CLA327100N1101 10
Gray N3271 GR 2CLA327100N1701 10
Kit IP55 push button - flush mounted Anthracite N3271 AN 2CLA327100N1801 10
Kit with:
- N3271 BL: IP55 frame for flush mounting - 1-gang - 2
modules. Flush mounting frames - IP55 - 2+2 modules
- N2204 BL: 1-gang, 1-way, NO push button / 127 - 250 Vac Frames for IP55 flush mounted vertical and horizontal
/ 16 A. installations.
- 1-gang, 2 module mounting plate. 2-gang - 2+2 modules.
Protection degree: IP55 (with lid closed). For 1 or 2 module devices.
Color: white. Size (height x width): 161 x 90 mm.
Opening angle of the lid: 120°. Included: two 1-gang, 2 module mounting plate.
The lid allows operating the push button in closed Protection degree: IP55 (with lid closed).
position. Opening angle of the lid: 120°. 11
The lid allows operating the switch in closed position.
Suitable for 60mm screw distance boxes.
White N3004 2CLA300400N1101 10
Kit IP55 Schuko socket outlet - flush mounted
Kit with: White N3272 BL 2CLA327200N1101 5
- N3271 BL: IP55 frame for flush mounting - 1-gang - 2 Gray N3272 GR 2CLA327200N1701 5
modules. Anthracite N3272 AN 2CLA327200N1801 5
- N2288 BL: Schuko socket outlet / 127 - 250 Vac / 16 A.
- 1-gang, 2 module mounting plate.
Protection degree: IP55 (with lid closed). Flush mounting frames - IP55 - 3 modules
Color: white. Frames for IP55 flush mounted horizontal installations.
Opening angle of the lid: 120°. 1-gang - 3 modules.
For 1, 2 or 3 module devices.
Size (height x width): 90 x 122 mm.
Included: one 1-gang, 3 module mounting plate.
White N3088 2CLA308800N1101 10 Protection degree: IP55 (with lid closed).
Opening angle of the lid: 120°.
The lid allows operating the switch in closed position.
Suitable for 83,5mm screw distance 3 module boxes.

White N3373 BL 2CLA337300N1101 5
Gray N3373 GR 2CLA337300N1701 5
Anthracite N3373 AN 2CLA337300N1801 5
