Page 1665 - Din prodcuts 2020

11/559

—
Unno
Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

American earthed socket outlet - 1M USB charger 750mA, 1-gang - 1M
Rated voltage: 125 Vac. Input voltage: 100 - 240 Vac ±10% ; 50/60 Hz.
Rated current: 15 A. Input current: 0,12 A (with maximum load).
Type B: 2P + E / NEMA 5-15R. Output voltage: 5 Vdc ±5 %.
Shuttered for child safety. Output current: 750 mA.
Screw terminals. Power consuption in stand-by: <= 0,3W@230Vac.
Energy efficiency: >= 66 %.
White N1128 BL 2CLA112800N1103 30
Operating Temperature: 0 °C to 45 °C.
White N1185 BL 2CLA118500N1103 1
American earthed duplex socket outlet - 3M
Rated voltage: 125 Vac.
Rated current: 15 A. USB charger 2.000mA, 1-gang - 1M
Type B: 2P + E / NEMA 5-15R. Input voltage: 100 - 230 Vac ±10%; 50/60 Hz.
Duplex outlet. Input current: 0,20 A (with maximum load).
Shuttered for child safety. Output voltage: 5 Vdc ±5%.
Screw terminals. Output current: 2.000 mA.
Power consumption in stand-by: <= 0,01W@230Vac.
White N1328 BL 2CLA132800N1103 20
Energy efficiency: >= 79%.
Operating temperature: 0 °C to 45 °C.
Euro-American unearthed socket outlet - 1M White N1185.2 BL 2CLA118520N1103 1
Rated voltage: 125 / 250 Vac.
Rated current: 15 / 16A.
Type A+C: 2P (non-earthed) / NEMA 1-15R.
Screw terminals.

White N1135 BL 2CLA113500N1103 30 11

Euro-American earthed socket outlet - 1M
Rated voltage: 110 - 250 Vac.
Rated current: 15 / 16 A.
Type B+C: 2P + E / NEMA 5-15R.
Shuttered for child safety.
Screw terminals.
White N1138 BL 2CLA113800N1103 30

Euro-American earthed duplex socket outlet - 3M
Rated voltage: 110 - 250 Vac.
Rated current: 15 / 16 A.
Type B+C: 2P + E / NEMA 5-15R.
Shuttered for child safety.
Screw terminals.
White N1338 BL 2CLA133800N1103 20

Brazilian 10A socket outlet - 1M
Rated voltage: 110 - 250 Vac.
Rated current: 10 A.
Type N: 2P + E.
Shuttered for child safety.
Screw terminals.
White N1136 BL 2CLA113600N1103 20
Red N1136 RJ 2CLA113600N7003 20

Brazilian 20A socket outlet - 1M
Rated voltage: 110 - 250 Vac.
Rated current: 20 A.
Type N: 2P + E.
Shuttered for child safety.
Screw terminals.
White N1136.2 BL 2CLA113620N1103 20
Red N1136.2 RJ 2CLA113620N7003 20
