Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

TV terminal outlet F-type - 1M 2x RCA connection unit - 1M
Single TV outlet - Dead-end. Front: 2x RCA connectors (Red / White).
F type. Rear: screw terminals (4 wires).
For 75Ω impedance coaxial cable.
Frequency range: 0 - 2.000 Mhz.
Working voltage: 250 VRMS max.
Dielectric withstanding voltage: 500 VRMS min.
Contact resistance: White N1155.2 BL 2CLA115520N1103 1
- 5 mΩ max. (center contact).
- 2 mΩ max. (outer contact). 3x RCA connection unit - 1M
Insulator resistance: 1.000 MΩ min. Front: 3x RCA connectors (Red / White / Yellow).
Rear: screw terminals (6 wires).
White N1150 BL 2CLA115000N1103 10

Telephone outlet RJ11 - 1M
RJ11 type connector. White N1155.3 BL 2CLA115530N1103 1
4 contacts.
Suitable for 2 or 4 contacts jack.
Screw terminals. Mini-Jack connection unit - 1M
Front: 1x Mini-Jack connector
(3,5 mm. stereo audio jack).
White N1117 BL 2CLA111700N1103 10
Rear: screw terminals (3/4 wires).
Data outlet RJ45 Cat.5e UTP
RJ45 type connector. White N1155.4 BL 2CLA115540N1103 1
Cat.5e UTP.
In compliance with ANSI/TIA/EIA 568B.2 ,
11
ISO/IEC11801 & EN50173. VGA connection unit - 1M
Universal TIA/EIA 568A and 568B labeling. Front: 1x VGA connector (DE-15 connector).
Housing: ABS UL-94-0. Rear: screw terminals (15 wires).
Durability: 750 cycles min. (ISO/IEC 11801,
IEC 60603-7-4).
IDC: PC UL94V-0, Accept 22-26AWG solid wire.
Contact: RJ45 8P8C, 3~50 micro-inch gold plating over
nickel plated on contact area. White N1155.5 BL 2CLA115550N1103 1
Tool-less wiring.
To be installed with N2118.1, N2218.1 and N2218.2 HDMI connection unit - 1M
cover plates. Front: 1x HDMI connector (Type A connector).
White N1118.5 BL 2CLA111850N1103 10 Rear: screwless terminals (20 wires).

Data outlet RJ45 Cat.6 UTP
RJ45 type connector. White N1155.6 BL 2CLA115560N1103 1
Cat.6 UTP.
In compliance with ANSI/TIA/EIA 568B.2 ,
ISO/IEC11801 & EN50173. HDMI female-female connection unit - 1M
Universal TIA/EIA 568A and 568B labeling. Front: 1x HDMI connector (Type A connector).
Housing: ABS UL-94-0. Rear: 1x HDMI connector (Type A connector)
Durability: 750 cycles min. (ISO/IEC 11801, fitted at 90º angle.
IEC 60603-7-4).
IDC: PC UL94V-0, Accept 22-26AWG solid wire.
Contact: RJ45 8P8C, 3~50 micro-inch gold plating over
nickel plated on contact area. White N1155.7 BL 2CLA115570N1103 1
Tool-less wiring.
To be installed with N2118.1, N2218.1 and N2218.2 USB connection unit - 1M
cover plates. Front: 1x USB 2.0 connector (Type A connector).
White N1118.6 BL 2CLA111860N1103 10 Rear: screwless terminals (5 wires).

White N1155.8 BL 2CLA115580N1103 1

USB female-female connection unit - 1M
Front: 1x USB 2.0 connector (Type A connector).
Rear: 1x USB 2.0 connector (Type A connector)
fitted at 90º angle.

White N1155.9 BL 2CLA115590N1103 1
