11/561

—
Unno
Blind control Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Push-button blind control 1-gang - 1M Rotatory/push dimmer 127V - 1M
Rated voltage: 110 - 250 Vac. Rated voltage: 110 - 127 Vac.
Rated current: 6A. Incandescent lamps: 50 - 500 W.
Miniswitch. Halogen lamps: 50 - 500 W.
Direct control Overload and short-circuit protection with fuse
(Not resetable).
White N1144 BL 2CLA114400N1103 10 White N1160 BL 2CLA116000N1103 10

Switch blind control 1-gang - 1M Rotatory/push dimmer 220V - 2M
Rated voltage: 110 - 250 Vac. Rated voltage: 220 - 230 Vac.
Rated current: 6A. Incandescent lamps: 50 - 700 W.
Miniswitch. Halogen lamps: 50 - 700 W.
Direct control. Overload and short-circuit protection with fuse
(Not resetable).
White N1144.1 BL 2CLA114410N1103 10 White N1160.1 BL 2CLA116010N1103 10
Various Rotatory LED Triac dimmer - 1M
Rated voltage: 110 - 230 Vac.
Buzzer - 1M Frequency: 50/60 Hz
Rated voltage: 110 - 230 Vac. Power min. load: 3 W
Sound level at 1 meter: 75dB. Power max. load (127 / 230 Vac):
Adjustable volume with screwdriver. - LEDi: 50 / 100 W (max. 10 lamps).
- LEDi with LC transformer: 50 / 100 W (max. 10 lamps).
- Halogen with LC transformer: 100 / 200 W. 11
- Incandescent lamps: 150 / 250 W.
White N1119 BL 2CLA111900N1103 10
2 wire connection.
OFF position
Cable outlet - 1M White N1160.2 BL 2CLA116020N1103 1
Includes a clamp to fix the cable.
LED/Universal rotatory dimmer 220V - 1M
Rated voltage: 230 Vac ± 10%.
Frequency: 50-60 Hz.
Power (min./max load):
White N1107 BL 2CLA110700N1103 10
- LEDi (trailing-edge lamps): 4 / 250 W/VA.
- LEDi (leading-edge lamps): 4 / 60 W/VA.*
Blank cover - 1M - LV LEDi with transformer type C: 4 / 250 W/VA.
- LV LEDi with transformer type LC: 4 / 60 W/VA.*
- LV halogen with transformer type C: 4 / 250 W/VA.
- LV halogen with transformer type LC: 4 / 250 W/VA.
- Incandescent lamps: 4 / 250 W/VA.
- Halogen lamps: 4 / 250 W/VA.
*Max. 10 lamps.
White N1100 BL 2CLA110000N1103 20
Load selection
2 or 3 wire connection.
OFF position
White N1160.3 BL 2CLA116030N1103 1

LED/Universal rotatory dimmer 110V - 1M
Rated voltage: 127 Vac ± 10%.
Frequency: 60 Hz.
Power (min./max load):
- LEDi (trailing-edge lamps): 4 / 125 W/VA.
- LEDi (leading-edge lamps): 4 / 30 W/VA.*
- LV LEDi with transformer type C: 4 / 125 W/VA.
- LV LEDi with transformer type LC: 4 / 30 W/VA.*
- LV halogen with transformer type C: 4 / 125 W/VA.
- LV halogen with transformer type LC: 4 / 125 W/VA.
- Incandescent lamps: 4 / 125 W/VA.
- Halogen lamps: 4 / 125 W/VA.
*Max. 10 lamps.
Load selection
2 or 3 wire connection.
OFF position.
White N1160.8 BL 2CLA116080N1103 1
