Page 1819 - Din prodcuts 2020

14/5

—
ABB i-bus® KNX
Power Supply

Power Supply, 160 mA, MDRC
KNX power supplies generate and monitor the KNX system voltage (SELV). The bus line is
decoupled from the power supply by an integrated choke.
The voltage output is short-circuit and overload protected.
The two-color LED indicates device output status. With two-coloured status indicator and
wide range input from 85…265 V AC, 50/60 Hz.

SV/S 30.160.1.1 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
4 SV/S 30.160.1.1 2CDG110144R0011 0.30 1

Power Supply, 320 mA, MDRC
KNX power supplies generate and monitor the KNX system voltage (SELV). The bus line is
decoupled from the power supply by an integrated choke.
The voltage output is short-circuit and overload protected.
The two-color LED indicates device output status.
With two-coloured status indicator and wide range input from 85…265 V AC, 50/60 Hz.
SV/S 30.320.1.1 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
4 SV/S 30.320.1.1 2CDG110166R0011 0.30 1

Power Supply, 640 mA, MDRC
KNX power supplies generate and monitor the KNX system voltage (SELV). The bus line is
decoupled from the power supply by an integrated choke. The voltage output is short-circuit
and overload protected.
The two-color LED indicates device output status. 14
Device type SV/S 30.640.3.1 has an additional 30 V DC short-circuit and overload protected
voltage output that can be used to power an additional bus line (in combination with a
SV/S 30.640.3.1 separate choke).
With two-coloured status indicator and wide range input from 85…265 V AC, 50/60 Hz.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
4 SV/S 30.640.3.1 2CDG110167R0011 0.30 1
