ABB i-bus® KNX
Heating, Ventilation and Air Conditioning

Thermoelectric Valve Drives
For opening and closing valves in heating, ventilation and air-conditioning systems. Both
variants (230 V and 24 V) feature a plug-in connection cable (1 m) and a splash-proof hous-
ing. The mounting on the valve is easily implemented using the Valve Adapter VA/Z xx.1.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
TSA/K 230.2
Type code Order code kg pc.
230 V – TSA/K 230.2 2CDG120049R0011 0.16 1
24 V – TSA/K 24.2 2CDG120050R0011 0.16 1
Valve Adapter for valves – VA/Z 10.1 2CDG120009R0011 0.06 1
from Dumser, Chronatherm,
Vescal, KaMo
Valve Adapter for valves – VA/Z 50.1 2CDG120010R0011 0.05 1
from Honeywell, Reich,
Cazzaniga, Landis & Gyr.
MNG
Valve Adapter for valves – VA/Z 78.1 2CDG120011R0011 0.03 1
from Danfoss RA
Valve Adapter for valves – VA/Z 80.1 2CDG120012R0011 0.06 1
from Heimeier, Herb, Onda,
Schlösser (ab 93), Oventrop

Split Unit Gateway, FM
The Split Unit Gateway forms the interface between the KNX system and many manufactur-
ers’ air conditioners, so-called split units. The device converts the KNX telegrams into infra-
red commands and transmits them to the split unit. The transmitter of the supplied cable is
bonded directly onto the split unit’s receiver. The split unit then no longer receives the com-
mands from a remote control. Instead, it can be operated via any KNX sensors or via a visual
display system. The device is put into operation with the ETS, and a free ETS app is available
to select the split unit model. Auxiliary voltage is not required.
SUG/U 1.1
14
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– SUG/U 1.1 2CDG110207R0011 0.02 1
