14/120 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
Energy Management

Energy Analyzer, M-Bus, MDRC*
Compact and web-based stand-alone devices for energy management applications.
For monitoring, logging, displaying and analyzing consumption data of up to 16 or 64 elec-
tricity, gas, water or heat meters via M-Bus. Automatic detection for ABB EQ meters
(A/B-Series). Access to the device via web browser. The user interface provides graphical
analysis functions, e.g. dashboard, historical data, instantaneous values, benchmark func-
tions, cost allocation according to consumer groups and more. For further processing data
can be exported cyclically (e.g. every month) via E-mail or upload to FTP server.
Several data sharing options (e.g. Modbus TCP, Rest API) allow the communnication with
QA/S 3.16.1
other systems.
* Pure M-Bus Master, no data routing from M-Bus to KNX

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
M-bus, 16 Devices 4 QA/S 3.16.1 2CDG110226R0011 0.15 1
M-bus, 64 Devices 4 QA/S 3.64.1 2CDG110227R0011 0.15 1

QA/S 3.64.1

Energy Analyzer, Modbus, MDRC*
Compact and web-based stand-alone devices for energy management applications.
For monitoring, logging, displaying and analyzing consumption data of up to 16 or 64 elec-
tricity, gas, water or heat meters via Modbus RTU. Automatic detection for ABB EQ meters
(A/B-Series). Access to the device via web browser. The user interface provides graphical
analysis functions, e.g. dashboard, historical data, instantaneous values, benchmark func-
tions, cost allocation according to consumer groups and more. For further processing data
can be exported cyclically (e.g. every month) via E-mail or upload to FTP server. Several data
sharing options (e.g. Modbus TCP, Rest API) allow the communnication with other systems.
QA/S 4.16.1
* Pure Modbus RTU Master, no data routing from Modbus RTU to KNX
14
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Modbus RTU, 16 Devices 4 QA/S 4.16.1 2CDG110228R0011 0.15 1
Modbus RTU, 64 Devices 4 QA/S 4.64.1 2CDG110229R0011 0.15 1

QA/S 4.64.1
