ABB i-bus® KNX
User Operation – Design Ranges – ABB Tenton®

Room Temperature Controller with Control Element, 10-fold
Freely configurable multifunction control element. With integrated KNX bus coupler. With la-
belling field. Support of KNX functions through innovative colour concept (yellow=lighting,
blue=blind, orange=RTC, magenta=scene and white=neutral/no function assigned) or stan-
dard illumination red/green. Push switch function: switching / dimming / blind / sending
values / scenes etc. Master/slave configuration. With base-load operation. The controller is a
constant room temperature controller for ventilator convectors (fan coils) in 2-pipe and
4-pipe systems and conventional heating or cooling systems. The fan stage can be switched
manually or in automatic mode. Class of temperature controller 1.

Description Mod. Order details Price Weight Pack
SBR/U10.0.1-84 width 1 piece 1 piece unit
Type code Order code kg pc.
davos/studio white – SBR/U10.0.1-84 2CKA006330A0008 1

RTC with CO 2 /Humidity Sensor and Control Element
Control element with room temperature controller function and CO 2 /moisture/air pressure
sensor. With integrated KNX bus coupler. With labelling field. Support of KNX functions
through innovative colour concept (yellow=lighting, blue=blind, orange=RTC, magen-
ta=scene and white=neutral/no function assigned) or standard illumination red/green. Push
switch function: switching / dimming / blind / sending values / scenes etc. For activating
heating, ventilation and fan coil actuators. Master/slave configuration. With base-load oper-
ation. The fan stage can be switched manually or in automatic mode. Class of temperature
SBC/U6.0.1-84 controller 1.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
davos/studio white, 6-fold – SBC/U6.0.1-84 2CKA006330A0010 1
davos/studio white, 10-fold – SBC/U10.0.1-84 2CKA006330A0012 1 14

Control Element
With integrated KNX bus coupler. With labelling field. Support of KNX functions through in-
novative colour concept (yellow=lighting, blue=blind, orange=RTC, magenta=scene and
white=neutral/no function assigned) or standard illumination red/green.
Push switch function: switching / dimming / blind / sending values / scenes etc. With inte-
grated temperature sensor. Number of bus subscribers: 1

Description Mod. Order details Price Weight Pack
SB/U8.0.1-84 width 1 piece 1 piece unit
Type code Order code kg pc.
davos/studio white, 8-fold – SB/U8.0.1-84 2CKA006330A0014 1
davos/studio white, 12-fold – SB/U12.0.1-84 2CKA006330A0016 1
