ABB i-bus® KNX
User Operation – Design Ranges –
Standard Control Elements

The standard control elements are They can also be used in commercial Customised text. Pictograms can be
available as 1/2gang, 2/4gang or applications. Anti-theft protection has applied to push buttons for easier ori-
4/8gang models. Every switch rocker also been integrated – an important entation. A clear text template with
has two LEDs, which display the status factor for installations in public areas. standard symbols is included for every
of the connected loads. The separate sensor. The self-explanatory picto-
switch rockers are freely programma- grams are available for the complete
ble and are suitable for switching and range of building control technology
dimming, and also for operating blinds and if necessary can be easily replaced.
and as a light scene extension unit. If the appropriate symbol is not in-
cluded, the push buttons can be la-
belled as desired. The related bus-cou-
pler unit is included in delivery.

01 02 03

Function Function Function
Switching | Dimming | Blinds | Switching | Dimming | Blinds | Switching | Dimming | Blinds |
Push-button | Value transmitter | Push-button | Value transmitter | Push-button | Value transmitter |
Light scene extension unit Light scene extension unit Light scene extension unit

Features Features Features
Labellable switch rockers | Labellable switch rockers | Labellable switch rockers |
Anti-theft protection | Freely Anti-theft protection | Freely Anti-theft protection | Freely
14
programmable switches | programmable switches | programmable switches |
Status/orientation light Status/orientation light Status/orientation light
(red/green/OFF) (red/green/OFF) (red/green/OFF)

01 Standard control element 1/2gang
02 Standard control element 2/4gang
03 Standard control element 4/8gang
