          ABB i-bus® KNX
          User Operation – Design Ranges –
          Room Temperature Controller


                                    Room temperature controller with 5gang universal input, FM
                                    Control element with room thermostat function for triggering the heating, ventilation and
                                    fan-coil actuators. With display of set-value temperature, master/slave configuration and
                                    base load operation. With universal inputs: a) max. of 5 binary inputs b) 4 binary inputs and
                                    1 analogue input for activating sensors with external power supply 1 – 10 V/0 – 10 V or c) 2 bi-
                                    nary inputs and 1 analogue input for activating sensors with external power supply
                                    1 – 10 V/0 – 10 V and an external temperature sensor PT1000/T6226.
          6109/18-500
                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit

                                                              Type code     Order code           kg      pc.
                                                         –    6109/18-500   2CKA006134A0315      0.144   1



                                    Room temperature controller with CO 2 /moisture sensor, FM
                                    Control element with room thermostat function and CO 2  moisture/air pressure sensor or
                                    triggering the heating, ventilation and fan-coil actuators. With display of set-value tempera-
                                    ture, master/slave configuration and base load operation. With universal inputs:
                                    a) max. of 5 binary inputs b) 4 binary inputs and 1 analogue input for activating sensors with
                                    external power supply 1 – 10 V/0 – 10 V or c) 2 binary inputs and 1 analogue input for activat-
                                    ing sensors with external power supply 1 – 10 V/0 – 10 V and an external temperature sensor
          6109/28-500               PT1000/T6226.

                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit

                                                              Type code     Order code           kg      pc.
                                                         –    6109/28-500   2CKA006134A0317      0.122   1
