ABB i-bus® KNX
User Operation – Design Ranges –
Zenit

3/6-fold sensor
Push switch function: switching / dimming / blind / sending values / scenes etc. Incl.
10 logic channels (light scene actuator, sequence actuator, logic gates, etc.)
Control element: Switch contacts. Display elements: LED to indicate the function. Protection
class (Device): IP 20. Temperature range (Device): – 5 °C to 45 °C.
Dimensions: (L x W x D): 44 mm x 44 mm.

6129/96-509
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6129/96-509 2CKA006118A0105 0.08 1

Cover Zenit 3/6-fold
Cover Zenit 3/6-fold. Available in white (BL), anthracite (AN) and silver (PL).

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
N2221.6 white – N2221.6 BL 2CLA222160N1101 0.011 1
anthracite – N2221.6 AN 2CLA222160N1801 0.011 1
silver – N2221.6 PL 2CLA222160N1301 0.011 1

3/6-fold sensor with IR
Push switch function: switching / dimming / blind / sending values / scenes etc. Incl.
10 logic channels (light scene actuator, sequence actuator, logic gates, etc.). With infrared.
Control element: Switch contacts. Display elements: LED to indicate the function.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit 14
6129/98-509
Type code Order code kg pc.
– 6129/98-509 2CKA006118A0108 0.088 1

Cover Zenit 3/6-fold with IR
Cover Zenit 3/6-fold with IR. Available in white (BL), anthracite (AN) and silver (PL).

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
N2221.7
white – N2221.7 BL 2CLA222170N1101 0.011 1
anthracite – N2221.7 AN 2CLA222170N1801 0.011 1
silver – N2221.7 PL 2CLA222170N1301 0.011 1
