P. 2087
14/273
—
ABB i-bus® KNX
User Operation – Design Ranges –
Zenit
Buttons with symbols
Buttons with symbols for Zenit control covers 1 / 2-gang, 2 / 4-gang, 3 / 6-gang and
3 / 6-gang with infrared.
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Symbol for marking “Light” – 6123/20-500 2CKA006123A0001 0.011 10
Symbol for marking “blinds” – 6123/21-500 2CKA006123A0002 0.011 10
Symbol for marking “scene” 6123/22-500 2CKA006123A0003 0.011 10
Symbol for marking – 6123/23-500 2CKA006123A0004 0.011 10
“temperature”
Symbol for marking – 6123/24-500 2CKA006123A0005 0.003 10
“ceiling light”
Symbol for marking – 6123/26-500 2CKA006123A0006 0.003 10
“Fan Coil”
Frames, 1 window, Zenit VDE
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – N2271 BL 2CLA227100N1102 0.032 1
silver – N2271 PL 2CLA227100N1302 0.03 1
N2271 XX
anthracite – N2271 AN 2CLA227100N1802 0.03 1
champagne – N2271 CV 2CLA227100N1902 0.031 1
wengué – N2271 WG 2CLA227100N2102 0.043 1
slate – N2271 PZ 2CLA227100N2202 0.92 1
white glass – N2271 CB 2CLA227100N3002 0.083 1
black glass – N2271 CN 2CLA227100N3102 0.083 1
14
pearl glass – N2271 CP 2CLA227100N3502 0.085 1
coffee glass – N2271 CC 2CLA227100N3702 0.083 1
graphite glass – N2271 CF 2CLA227100N3802 0.085 1
champagne glass – N2271 CH 2CLA227100N3902 0.085 1
stainless steel – N2271 OX 2CLA227100N4002 0.2 1
Basic frame, 1 window, Zenit VDE
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – N2271.1 BL 2CLA227110N1102 0.021 1
silver – N2271.1 PL 2CLA227110N1302 0.021 1
anthracite – N2271.1 AN 2CLA227110N1802 0.019 1
champagne – N2271.1 CV 2CLA227110N1902 0.02 1
