15/14 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB-free@home®
System devices

System Access Point 2.0
For commissioning and remote control of the ABB-free@home® system.
Support for up to 150 free@home participants (independent of whether wireless or wired).
With integrated free@home wireless antenna.
With integrated free@home bus connection.
Easy to mount thanks to the external power adapter (included in the scope of delivery).
Optional supply via the yellow/white twisted pair of the bus line (24 V).
Allows the execution of astro and time programs.
Commissioning and remote control is executed via the web interface or app.
No additional commissioning software is required.
Easy commissioning with WLAN ad-hoc mode.
Connection to the home network via WLAN client mode or via CAT cable.
Suitable as table device.
Suitable for wall mounting.
2 x USB ports for future extension of functions.
2.4 GHz and 5 GHz WLAN
1 GHz dual core processor
512 MB working storage
Scope of delivery: Mounting plate, power adapter, screws and dowels
The bus connection is provided via the enclosed bus terminal.
Display elements: LED for status display.
Bus voltage: 24 V
Rated voltage: 230 V~
Rated frequency: 50 Hz / 60 Hz
Protection class (device): IP 20
Temperature range (device): -5 °C - 45 °C
Storage temperature range: -20 °C - 70 °C
Dimensions: (L x W x D): 107 mm x 109 mm x 30 mm
Programming via the web interface of the System Access Point.
Additional information about commissioning and operation is contained in the system manual
and the online operating manual of the current Online-Catalogue.
A bus power supply is required for the operation of free@home wired devices.
When operating with more than 64 participants, an additional bus power supply is required.

Rated voltage: 230 V~
15
Bbn Order details Price Weight Pack
4011395 1 piece 1 piece unit

EAN Type code Order code kg pc.
WIRELESS
84 studio white NEW 261583 SAP/S.3 2CKA006200A0155 1
