15/18 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB-free@home®
Displays

IP touch 7'', white
Description The stylish multifunctional IP touch panel fits elegantly into any interior. Thanks to its
intuitive design, the IP touch panel will display everything that is happening in front
of your door. In addition, the panel can be a centralized screen for other ABB sub-system,
like CCTV, access control and home automation.
Features - Intuitive GUI on sliding screen (1024 x 600)
- Clean & consistent design with invisible mic & speaker hole
- Slim thickness with 7.8 mm when flush mounted
- Color,material, End trip & mounting type selectable
- Extension to App without additional system device
- Central control panel to DES,Smart lock,Surveillance,Basic alarm, Home automation
(KNX & F@H),Environmental health,Energy management
- API & Web-browser enable easy 3rd party integration
- Cyber security and data privacy
- Easy installation in all kind of walls
- Easy commissioning by QR code scaning or central PC management software
- PoE and local power supply optional
- Remote fireware update
Technical - Flush mounting and surface mounting
details - Dustproof and waterproof as IP30
- Dimensions: 139 x 150 x 36 mm
LAN + WiFi interface LAN + WiFi interface LAN + LAN interface
Version
with induction loop
Article no. H82361-W H82364-W H82362-W
Order no. 2TMA130050W0001 2TMA130050W0004 2TMA130050W0002
LAN + LAN interface LAN interface LAN interface
Version
with induction loop with induction loop
Article no. H82365-W H82363-W H82366-W
Order no. 2TMA130050W0005 2TMA130050W0003 2TMA130050W0006

IP touch 7'', black
Description The stylish multifunctional IP touch panel fits elegantly into any interior. Thanks to its
intuitive design, the IP touch panel will display everything that is happening in front
of your door. In addition, the panel can be a centralized screen for other ABB sub-system,
like CCTV, access control and home automation.
Features - Intuitive GUI on sliding screen(1024 x 600)
- Clean & consistent design with invisible mic & speaker hole
- Slim thickness with 7.8 mm when flush mounted
- Color,material, End trip & mounting type selectable
- Extension to App without additional system device
- Central control panel to DES,Smart lock,Surveillance,Basic alarm, Home automation
(KNX & F@H),Environmental health,Energy management
15
- API & Web-browser enable easy 3rd party integration
- Cyber security and data privacy
- Easy installation in all kind of walls
- Easy commissioning by QR code scaning or central PC management software
- PoE and local power supply optional
- Remote fireware update
Technical - Flush mounting and surface mounting
details - Dustproof and waterproof as IP30
- Dimensions: 139 x 150 x 36 mm
LAN + WiFi interface LAN + WiFi interface LAN + LAN interface
Version
with induction loop
Article no. H82361-B H82364-B H82362-B
Order no. 2TMA130050B0001 2TMA130050B0004 2TMA130050B0002
LAN + LAN interface LAN interface LAN interface
Version
with induction loop with induction loop
Article no. H82365-B H82363-B H82366-B
Order no. 2TMA130050B0005 2TMA130050B0003 2TMA130050B0006
