16/40 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Door entry system
ABB-Welcome IP - Video indoor stations

IP touch 7'', white
Description The stylish multifunctional IP touch panel fits elegantly into any interior. Thanks to its
intuitive design, the IP touch panel will display everything that is happening in front
of your door. In addition, the panel can be a centralized screen for other ABB sub-system,
like CCTV, access control and home automation.
Features - Intuitive GUI on sliding screen (1024 x 600)
- Clean & consistent design with invisible mic & speaker hole
- Slim thickness with 7.8 mm when flush mounted
- Color,material, End trip & mounting type selectable
- Extension to App without additional system device
- Central control panel to DES,Smart lock,Surveillance,Basic alarm, Home automation
(KNX & F@H),Environmental health,Energy management
- API & Web-browser enable easy 3rd party integration
- Cyber security and data privacy, - Easy installation in all kind of walls
- Easy commissioning by QR code scaning or central PC management software
- PoE and local power supply optional, - Remote fireware update
Technical - Flush mounting and surface mounting
details - Dustproof and waterproof as IP30
- Dimensions: 199 x 150 x 17 mm (LAN+WiFi) 199 x 150 x 30 mm (LAN+LAN)
support DES, LAN, support DES, LAN, support DES+APP, support DES+APP,
DC&PoE, full glass, DC&PoE, with T-loop, LAN + WiFi, PoE, full LAN + WiFi, DC&PoE,
Version
SM&FM, white end strip, SM&FM, glass, SM&FM, with full glass, SM&FM,
white SM box delivery, white white
Article no. H8236-1WG H82366-W H82364-WG H8236-2WG
Order no. 2TMA130050W0061 2TMA130050W0006 2TMA130050W0053 2TMA130050W0062
support DES+HA, support DES+HA, with cyber security with cyber security
LAN + WiFi, DC&PoE, LAN + LAN, DC&PoE, boot & storage, boot & storage,
full glass, SM&FM, full glass, FM, white support DES+HA+APP, support DES+HA+APP,
Version
white LAN + WiFi, DC&PoE, LAN + LAN, DC&PoE,
with T-loop, end strip, with T-loop, end strip,
SM&FM, white FM, white
Article no. H8236-8WG H8236-9WG H8236-4W H8236-5W
Order no. 2TMA130050W0063 2TMA130050W0064 2TMA130050W0065 2TMA130050W0067

IP touch 7'', black
Description The stylish multifunctional IP touch panel fits elegantly into any interior. Thanks to its
intuitive design, the IP touch panel will display everything that is happening in front
of your door. In addition, the panel can be a centralized screen for other ABB sub-system,
like CCTV, access control and home automation.
Features - Intuitive GUI on sliding screen(1024 x 600)
- Clean & consistent design with invisible mic & speaker hole
- Slim thickness with 7.8 mm when flush mounted
- Color,material, End trip & mounting type selectable
- Extension to App without additional system device
- Central control panel to DES,Smart lock,Surveillance,Basic alarm, Home automation
(KNX & F@H),Environmental health,Energy management
- API & Web-browser enable easy 3rd party integration
16
- Cyber security and data privacy, - Easy installation in all kind of walls
- Easy commissioning by QR code scaning or central PC management software
- PoE and local power supply optional, - Remote fireware update
Technical - Flush mounting and surface mounting
details - Dustproof and waterproof as IP30
- Dimensions: 199 x 150 x 17 mm (LAN+WiFi) 199 x 150 x 30 mm (LAN+LAN)
support DES, LAN, support DES, LAN, support DES+APP, support DES+APP,
DC&PoE, full glass, DC&PoE, with T-loop, LAN + WiFi, PoE, full LAN + WiFi, DC&PoE,
Version
SM&FM, black end strip, SM&FM, glass, SM&FM, with full glass, SM&FM,
black SM box delivery, black black
Article no. H8236-1BG H82366-B H82364-BG H8236-2BG
Order no. 2TMA130050B0061 2TMA130050B0006 2TMA130050B0053 2TMA130050B0062
support DES+HA, support DES+HA, with cyber security with cyber security
LAN + WiFi, DC&PoE, LAN + LAN, DC&PoE, boot & storage, boot & storage,
full glass, SM&FM, full glass, FM, black support DES+HA+APP, support DES+HA+APP,
Version
black LAN + WiFi, DC&PoE, LAN + LAN, DC&PoE,
with T-loop, end strip, with T-loop, end strip,
SM&FM, black FM, black
Article no. H8236-8BG H8236-9BG H8236-4B H8236-5B
Order no. 2TMA130050B0063 2TMA130050B0064 2TMA130050B0065 2TMA130050B0067
