16/60 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Access Control
ABB-AccessControl - Cylinders

Cylinder - European half profile
Description The cylinder is suitable for any interior or weather-proofed exterior door, making it a
very versatile solution. As there is no wiring whatsoever, mounting and replacement
is completed in next to no time, whether you are installing a cylinder for the first time
or retrofitting. The cylinder can be operated offline, in a local networked
configuration or online through internet.
Features - Simple installation and easy retrofit to traditional mechanical cylinder
- Different portfolios to meet different user scenarios
- Simple and intuitive design
- Highly security on mechanical protection and data transfer
- Easy and feasible configuration and daily management
Technical details Supported RFID standards
- MIFARE (DESFire EV1)
Radio interface:
- IEEE 802.15.4 2.4GHz radio
Power supply/service life
- Battery: 1 x 3 V CR2 lithium
- Battery life at 20°C: up to 50,000 cycles or up to 3 years
Environment
- Temperature: -25°C to +70°C
- Protection type: up to IP55 (outside)
- Humidity: 0 to 95%, non-condensing
Certification symbol
- CE,UL,CCC,FCC,IP66,RCM,EAC,WEEE

Version European profile half cylinder
Article no. Order no. Tech- Article no. Order no. Tech-
nical nical
data data
D01EU300003NF1-04 2CKA008300A1174 30/00 D01EU304003NF1-04 2CKA008300A1201 30/40
D01EU350003NF1-04 2CKA008300A1175 35/00 D01EU354003NF1-04 2CKA008300A1202 35/40
D01EU400003NF1-04 2CKA008300A1176 40/00 D01EU404003NF1-04 2CKA008300A1203 40/40
D01EU450003NF1-04 2CKA008300A1177 45/00 D01EU454003NF1-04 2CKA008300A1204 45/40
D01EU500003NF1-04 2CKA008300A1178 50/00 D01EU504003NF1-04 2CKA008300A1205 50/40
D01EU550003NF1-04 2CKA008300A1179 55/00 D01EU554003NF1-04 2CKA008300A1206 55/40
D01EU600003NF1-04 2CKA008300A1180 60/00 D01EU604003NF1-04 2CKA008300A1207 60/40
D01EU650003NF1-04 2CKA008300A1181 65/00 D01EU654003NF1-04 2CKA008300A1208 65/40
D01EU700003NF1-04 2CKA008300A1182 70/00 D01EU704003NF1-04 2CKA008300A1209 70/40
D01EU303003NF1-04 2CKA008300A1183 30/30 D01EU304503NF1-04 2CKA008300A1210 30/45
D01EU353003NF1-04 2CKA008300A1184 35/30 D01EU354503NF1-04 2CKA008300A1211 35/45
D01EU403003NF1-04 2CKA008300A1185 40/30 D01EU404503NF1-04 2CKA008300A1212 40/45
D01EU453003NF1-04 2CKA008300A1186 45/30 D01EU454503NF1-04 2CKA008300A1213 45/45
D01EU503003NF1-04 2CKA008300A1187 50/30 D01EU504503NF1-04 2CKA008300A1214 50/45
D01EU553003NF1-04 2CKA008300A1188 55/30 D01EU554503NF1-04 2CKA008300A1215 55/45
16
D01EU603003NF1-04 2CKA008300A1189 60/30 D01EU604503NF1-04 2CKA008300A1216 60/45
D01EU653003NF1-04 2CKA008300A1190 65/30 D01EU654503NF1-04 2CKA008300A1217 65/45
D01EU703003NF1-04 2CKA008300A1191 70/30 D01EU704503NF1-04 2CKA008300A1218 70/45
D01EU303503NF1-04 2CKA008300A1192 30/35 D01EU305003NF1-04 2CKA008300A1219 30/50
D01EU353503NF1-04 2CKA008300A1193 35/35 D01EU355003NF1-04 2CKA008300A1220 35/50
D01EU403503NF1-04 2CKA008300A1194 40/35 D01EU405003NF1-04 2CKA008300A1221 40/50
D01EU453503NF1-04 2CKA008300A1195 45/35 D01EU455003NF1-04 2CKA008300A1222 45/50
D01EU503503NF1-04 2CKA008300A1196 50/35 D01EU505003NF1-04 2CKA008300A1223 50/50
D01EU553503NF1-04 2CKA008300A1197 55/35 D01EU555003NF1-04 2CKA008300A1224 55/50
D01EU603503NF1-04 2CKA008300A1198 60/35 D01EU605003NF1-04 2CKA008300A1225 60/50
D01EU653503NF1-04 2CKA008300A1199 65/35 D01EU655003NF1-04 2CKA008300A1226 65/50
D01EU703503NF1-04 2CKA008300A1200 70/35 D01EU705003NF1-04 2CKA008300A1227 70/50
