Access Control
ABB-AccessControl - Cylinders

Cylinder - Swiss half profile
Description The cylinder is suitable for any interior or weather-proofed exterior door, making it a
very versatile solution. As there is no wiring whatsoever, mounting and replacement
is completed in next to no time, whether you are installing a cylinder for the first time
or retrofitting. The cylinder can be operated offline, in a local networked
configuration or online through internet.
Features - Simple installation and easy retrofit to traditional mechanical cylinder
- Different portfolios to meet different user scenarios
- Simple and intuitive design
- Highly security on mechanical protection and data transfer
- Easy and feasible configuration and daily management
Technical details Supported RFID standards
- MIFARE (DESFire EV1)
Radio interface:
- IEEE 802.15.4 2.4GHz radio
Power supply/service life
- Battery: 1 x 3 V CR2 lithium
- Battery life at 20°C: up to 50,000 cycles or up to 3 years
Environment
- Temperature: -25°C to +70°C
- Protection type: up to IP55 (outside)
- Humidity: 0 to 95%, non-condensing
Certification symbol
- CE,UL,CCC,FCC,IP66,RCM,EAC,WEEE

Version Swiss round profile half cylinder
Article no. Order no. Tech- Article no. Order no. Tech-
nical nical
data data
D01CH300003NF1-04 2CKA008300A1309 30/00 D01CH304003NF1-04 2CKA008300A1336 30/40
D01CH350003NF1-04 2CKA008300A1310 35/00 D01CH354003NF1-04 2CKA008300A1337 35/40
D01CH400003NF1-04 2CKA008300A1311 40/00 D01CH404003NF1-04 2CKA008300A1338 40/40
D01CH450003NF1-04 2CKA008300A1312 45/00 D01CH454003NF1-04 2CKA008300A1339 45/40
D01CH500003NF1-04 2CKA008300A1313 50/00 D01CH504003NF1-04 2CKA008300A1340 50/40
D01CH550003NF1-04 2CKA008300A1314 55/00 D01CH554003NF1-04 2CKA008300A1341 55/40
D01CH600003NF1-04 2CKA008300A1315 60/00 D01CH604003NF1-04 2CKA008300A1342 60/40
D01CH650003NF1-04 2CKA008300A1316 65/00 D01CH654003NF1-04 2CKA008300A1343 65/40
D01CH700003NF1-04 2CKA008300A1317 70/00 D01CH704003NF1-04 2CKA008300A1344 70/40
D01CH303003NF1-04 2CKA008300A1318 30/30 D01CH304503NF1-04 2CKA008300A1345 30/45
D01CH353003NF1-04 2CKA008300A1319 35/30 D01CH354503NF1-04 2CKA008300A1346 35/45
D01CH403003NF1-04 2CKA008300A1320 40/30 D01CH404503NF1-04 2CKA008300A1347 40/45
D01CH453003NF1-04 2CKA008300A1321 45/30 D01CH454503NF1-04 2CKA008300A1348 45/45
D01CH503003NF1-04 2CKA008300A1322 50/30 D01CH504503NF1-04 2CKA008300A1349 50/45
16
D01CH553003NF1-04 2CKA008300A1323 55/30 D01CH554503NF1-04 2CKA008300A1350 55/45
D01CH603003NF1-04 2CKA008300A1324 60/30 D01CH604503NF1-04 2CKA008300A1351 60/45
D01CH653003NF1-04 2CKA008300A1325 65/30 D01CH654503NF1-04 2CKA008300A1352 65/45
D01CH703003NF1-04 2CKA008300A1326 70/30 D01CH704503NF1-04 2CKA008300A1353 70/45
D01CH303503NF1-04 2CKA008300A1327 30/35 D01CH305003NF1-04 2CKA008300A1354 30/50
D01CH353503NF1-04 2CKA008300A1328 35/35 D01CH355003NF1-04 2CKA008300A1355 35/50
D01CH403503NF1-04 2CKA008300A1329 40/35 D01CH405003NF1-04 2CKA008300A1356 40/50
D01CH453503NF1-04 2CKA008300A1330 45/35 D01CH455003NF1-04 2CKA008300A1357 45/50
D01CH503503NF1-04 2CKA008300A1331 50/35 D01CH505003NF1-04 2CKA008300A1358 50/50
D01CH553503NF1-04 2CKA008300A1332 55/35 D01CH555003NF1-04 2CKA008300A1359 55/50
D01CH603503NF1-04 2CKA008300A1333 60/35 D01CH605003NF1-04 2CKA008300A1360 60/50
D01CH653503NF1-04 2CKA008300A1334 65/35 D01CH655003NF1-04 2CKA008300A1361 65/50
D01CH703503NF1-04 2CKA008300A1335 70/35 D01CH705003NF1-04 2CKA008300A1362 70/50
