Access Control
ABB-AccessControl - Cylinders

Cylinder - Swiss full profile
Description The cylinder is suitable for any interior or weather-proofed exterior door, making it a
very versatile solution. As there is no wiring whatsoever, mounting and replacement is
completed in next to no time, whether you are installing a cylinder for the first time or
retrofitting. The cylinder can be operated offline, in a local networked configuration or
online through internet.
Features - Simple installation and easy retrofit to traditional mechanical cylinder
- Different portfolios to meet different user scenarios
- Simple and intuitive design
- Highly security on mechanical protection and data transfer
- Easy and feasible configuration and daily management
Technical details Supported RFID standards
- MIFARE (DESFire EV1)
Radio interface:
- IEEE 802.15.4 2.4GHz radio
Power supply/service life
- Battery: 1 x 3 V CR2 lithium
- Battery life at 20°C: up to 50,000 cycles or up to 3 years
Environment
- Temperature: -25°C to +70°C
- Protection type: up to IP55 (outside)
- Humidity: 0 to 95%, non-condensing
Certification symbol
- CE,UL,CCC,FCC,IP66,RCM,EAC,WEEE
Version Swiss round profile cylinder with thumbturn
Article no. Order no. Tech- Article no. Order no. Tech-
nical nical
data data
D01CH303003TF1-04 2CKA008300A1363 30/30 D01CH505503TF1-04 2CKA008300A1404 50/55
D01CH303503TF1-04 2CKA008300A1364 30/35 D01CH506003TF1-04 2CKA008300A1405 50/60
D01CH304003TF1-04 2CKA008300A1365 30/40 D01CH506503TF1-04 2CKA008300A1406 50/65
D01CH304503TF1-04 2CKA008300A1366 30/45 D01CH507003TF1-04 2CKA008300A1407 50/70
D01CH305003TF1-04 2CKA008300A1367 30/50 D01CH553003TF1-04 2CKA008300A1408 55/30
D01CH305503TF1-04 2CKA008300A1368 30/55 D01CH553503TF1-04 2CKA008300A1409 55/35
D01CH306003TF1-04 2CKA008300A1369 30/60 D01CH554003TF1-04 2CKA008300A1410 55/40
D01CH306503TF1-04 2CKA008300A1370 30/65 D01CH554503TF1-04 2CKA008300A1411 55/45
D01CH307003TF1-04 2CKA008300A1371 30/70 D01CH555003TF1-04 2CKA008300A1412 55/50
D01CH353003TF1-04 2CKA008300A1372 35/30 D01CH555503TF1-04 2CKA008300A1413 55/55
D01CH353503TF1-04 2CKA008300A1373 35/35 D01CH556003TF1-04 2CKA008300A1414 55/60
D01CH354003TF1-04 2CKA008300A1374 35/40 D01CH556503TF1-04 2CKA008300A1415 55/65
D01CH354503TF1-04 2CKA008300A1375 35/45 D01CH557003TF1-04 2CKA008300A1416 55/70
D01CH355003TF1-04 2CKA008300A1376 35/50 D01CH603003TF1-04 2CKA008300A1417 60/30
