Access Control
ABB-AccessControl - Accessories

RF/IP Gateway
Description RF/IP Gateway is an easy solution to connect the cylinders to IP platform, so it is one
important device to extend the AC solution from residential to commercial, support more
than 16 doors, even there is long distance between each door.
Features - Scale up wireless access control system topology easily
• One RF/IP gateway can support another 16 cylinders
• Maximum 64 gateways can be connected
- Easy and fast configuration
• Bluetooth wireless installation with cylinders
• Graphical visual configuration through SmartAP web-based
interface, pair and link the locks simply and fast
- Different power solution to meet different requests
• PoE solution
• 24VDC plug-in power solution
- Firmware update remotely through SmartAP and APP
Technical details - Dimension: 107 x 109 x 30
- Radio interface: IEEE 802.15.4 2.4GHz radio
- Power supply: 24 V DC
- Environment:
- Temperature: -10°C to +45°C
- Protection type: IP30
- Vandal proof: IK07
- Humidity: 0 to 95%, non-condensing
Version White
Article no. D04031
Order no. 2TMA400260W0013

Tag
Description The tag is based on RFID chip technology. Available in electronic cylinders and ABB
outdoor readers. With a special encryption to ensure secure controlled access.
Features - 13.56 MHz contactless RFID identification, DESfireEV1 (256, 2K,4K,8K bytes)
- Compatible in all ABB devices
- Multi-color design
- Modern design with ID-number layout
- Waterproof
Technical details - 13.56MHz, Mifare DESfireEV1 chip
Version White
Article no. D051C1
Order no. 2CKA008300A0992

Maintenance tool
Description A professional tool to dismantle / fasten the knob, to install in new door, or replace
battery
16
Technical details - 13.56MHz, Mifare DESfireEV1 chip
Article no. D080MT-03
Order no. 2CKA008300A0997
