Access Control
ABB-AccessControl - System devices

Smart Access Point
Description A central management device of Welcome IP system, it can couple as sub-system, and also
manage interworking of multiple sub-system of same type. Commissioning and remote
control is executed via web interface. No additional commissioning software is required.
Connection to the network via WLAN client mode or via CAT cable to manage all your access,
configure all your devices, record your logs, etc.
Features - Easy to commissioning - Easy to commissioning
- Access rights, who, where, when… - Access rights, who, where, when…
- Enhanced security with record event log - Enhanced security with record event log
and receive notification and alert and receive notification and alert
- Manage all connected devices - Manage all connected devices
- Interaction between different systems - Interaction between different systems
- Manage welcome App - Manage welcome App
- Event management and building-wide - Event management and building-wide
messaging messaging
- Integrated chimey, easy for retrofit
- In-build BLE, the best choice for standalone
AC system
Technical - Dimension: 204 mm × 132 mm × 32 mm - Dimension: 204 mm × 132 mm × 32 mm
details - Network parameter: - Network parameter:
• Operating mode: • Operating mode:
LAN/Wireless access point LAN/Wireless access point
• Wireless transmission band: • Wireless transmission band:
IEEE 802.11 a/b/g/n 2.4 GHz/5.8 GHz IEEE 802.11 a/b/g/n 2.4 GHz/5.8 GHz
• Safety standard: WPA-PSK, WPA2-PSK, • Safety standard: WPA-PSK, WPA2-PSK,
WPA, WPA2, IEEE 802.1x WPA, WPA2, IEEE 802.1x
• Network connection standard: • Network connection standard:
10 / 100 Mbps, auto MDI/MDI-X 10 / 100 Mbps, auto MDI/MDI-X
- Power supply: - Radio interface: IEEE 802.15.4 2.4GHz radio
• 24VDC, together with ABB power adaptor - Power supply:
• PoE(Power over Ethernet) • 24VDC, together with ABB power adaptor
- Environment: • PoE(Power over Ethernet)
• Temperature: -10°C to +45°C - Environment:
• Protection type: IP30 • Temperature: -10°C to +45°C
• Vandal proof: IK07 • Protection type: IP30
• Humidity: 0 to 95%, non-condensing • Vandal proof: IK07
• Humidity: 0 to 95%, non-condensing
Version Pro Lite
Article no. D04012 D04011
Order no. 2TMA400260W0001 2TMA400260W0002

RF repeater
Description RF repeater is for indoor applications, wireless extension of radio range by integrated
antenna. No network knowledge is required for the wireless network. The RF repeater is
available in the elegant housings and can be combined with all VDE boxes, and also can be 16
surface-mounted on the wall.
Features - Scale up system topology easily
- Easy and fast configuration
- Different power solution to meet different requests
- Firmware update remotely
Technical details - Dimension: 90 x 90 x 28 mm
- Radio interface: IEEE 802.15.4 2.4GHz radio
- Power supply: 24 V DC, together with ABB power adaptor
- Environment:
• Temperature: -10°C to +45°C
• Protection type: IP30
• Vandal proof: IK07
• Humidity: 0 to 95%, non-condensing
Version White
Article no. D04021
Order no. 2TMA400260W0003
