Access Control
ABB-AccessControl - Cylinders

Cylinder - ANSI mortice profile
Description The cylinder is suitable for any interior or weather-proofed exterior door, making it a
very versatile solution. As there is no wiring whatsoever, mounting and replacement is
completed in next to no time, whether you are installing a cylinder for the first time or
retrofitting. The cylinder can be operated offline, in a local networked configuration or
online through internet.
Features - Simple installation and easy retrofit to traditional mechanical cylinder
- Different portfolios to meet different user scenarios
- Simple and intuitive design
- Highly security on mechanical protection and data transfer
- Easy and feasible configuration and daily management
Technical details Supported RFID standards
- MIFARE (DESFire EV1)
Radio interface:
- IEEE 802.15.4 2.4GHz radio
Power supply/service life
- Battery: 1 x 3 V CR2 lithium
- Battery life at 20°C: up to 50,000 cycles or up to 3 years
Environment
- Temperature: -25°C to +70°C
- Protection type: up to IP55 (outside)
- Humidity: 0 to 95%, non-condensing
Certification symbol
- CE,UL,CCC,FCC,IP66,RCM,EAC,WEEE

Version US mortise profile cylinder
Order no. Article no. Technical data
2CKA008300A0986 D01MO320005NF1-04 32/00 MO
2CKA008300A0987 D01MO350005NF1-04 36/00 MO
2CKA008300A0988 D01MO380005NF1-04 38/00 MO
2CKA008300A0989 D01MO410005NF1-04 41/00 MO
2CKA008300A0990 D01MO440005NF1-04 44/00 MO
2CKA008300A0991 D01MO500005NF1-04 50/00 MO
