16/68 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Access Control
ABB-AccessControl - Cylinders

Cylinder - ANSI rim profile
Description The cylinder is suitable for any interior or weather-proofed exterior door, making it a
very versatile solution. As there is no wiring whatsoever, mounting and replacement is
completed in next to no time, whether you are installing a cylinder for the first time or
retrofitting. The cylinder can be operated offline, in a local networked configuration or
online through internet.
Features Simple installation and easy retrofit to traditional mechanical cylinder
Different portfolios to meet different user scenarios
Simple and intuitive design
Highly security on mechanical protection and data transfer
Easy and feasible configuration and daily management
Technical details Supported RFID standards
- MIFARE (DESFire EV1)
Radio interface:
- IEEE 802.15.4 2.4GHz radio
Power supply/service life
- Battery: 1 x 3 V CR2 lithium
- Battery life at 20°C: up to 50,000 cycles or up to 3 years
Environment
- Temperature: -25°C to +70°C
- Protection type: up to IP55 (outside)
- Humidity: 0 to 95%, non-condensing
Certification symbol
- CE,UL,CCC,FCC,IP66,RCM,EAC,WEEE

Version US RIM profile cylinder
Order no. Article no. Technical data
2CKA008300A0983 D01US000008NF1-04 00/00
