18/42 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
A-Wall Cabinets IP43
Accessories

Article Pieces Type Order code
Insulating frame for cabinet to cabinet connection 1 ZX455 2CPX039192R9999
For the side flange cut-outs (to maintain double insulation when
cabinets are assembled next to each other)
(with connection material)
ZX455

Insulating frame for cabinet to cabinet connection 1 ZX454 2CPX039199R9999
For the top/bottom flange cut-outs (to maintain double
insulation when cabinets are assembled one above the other)
ZX454

External mounting brackets 4 ZX206P4 2CPX062491R9999
ZX206P4
Membrane flange* 1 ZB43 2CPX038183R9999
For inserting cables
ZB43

Nipple flange* 1 ZB40 2CPX038195R9999
For cable diameters 1 x 12 to 47 mm, 1 x 12 to 29 mm,
3 x 8 to 15 mm, 20 x 7 to 13 mm
ZB40
Standard lock* 1 ZB113 2CPX038478R9999
Safety lock 1 ZB111 2CPX038479R9999
With 2 keys

ZB113 ZB111
Espagnolette closure
In conjunction with the standard lock and safety lock
for subsequent installation in A-, B- and U-cabinets
For overall height 0 (4 GU) 1 ZX456 2CPX039586R9999
For overall height 1 (5 GU) 1 ZX457 2CPX039587R9999
For overall height 2 (6 GU) 1 ZX458 2CPX039588R9999
For overall height 3 (7 GU) 1 ZX459 2CPX039589R9999
For overall height 4 (8 GU) 1 ZX460 2CPX039590R9999
ZX456 For overall height 5 (9 GU) 1 ZX461 2CPX039591R9999

Installation set 1 ZH800 2CPX038544R9999
for actuation options in conjunction with ZH220/ZH221/ZH222

ZH800

Latch plate for double-bit operating pin 1 ZH220 2CPX045700R9999
(order installation set ZH800 separately)
3 mm and 5 mm

ZH220
18
Operating pins
Double-bit 3 mm 1 ZH130 2CPX060490R9999
ZH130 Double-bit 5 mm 1 ZH131 2CPX060491R9999
* Spare part included in the scope of delivery.
