Subdistribution boards
Examples of configurations

+0
1
3
+01 ESBN0610 +02 ESBN0310 +0 +03 ESBN0610
CACP40100
CKUC6020 CKUC6020
+02.10
+01.10 CVAC1511 +03.10
CKDD1620 CKDD1620
+02.20
+01.20 +03.20
CKDD1620 CACP4060 CKDD1620
+01.40 +03.40
CKBS1233
+02.30
CKDD1620 CKDD1620
+01.30 +03.30
CACP6020 CACP6020
+01.50 +02.40 +03.50

TwinLine S 55 (1000 x 600 x 225 mm + 1000 x 300 x 225 mm + 1000 x 600 x 225 mm) IP55,
Internal configuration CombiLine S, with busbars 250 A,10 kA in external cable container
Type Ord.no. Description Pcs.
ESWG0610 2CPX078569R9999 Structure TLS55, W 600 mm, H 1000 mm, D225 mm 2
ESFG0010 2CPX078599R9999 Side walls 2 pcs, D 225 mm, H 1000 mm 1
ESWG0310 2CPX078563R9999 Structure TLS55, W 300 mm, H 1000 mm, D 225 mm 1
ESIN0010 2CPX078423R9999 Installation set for internal configuration, H 1000 mm 3
ESAT0610 2CPX078180R9999 Transparent door, W 600 mm, H 1000 mm 2
ESAC3005 2CPX078415R9999 Connection set for side-by-side structuring of cabinets 2
TZ626 2CPX010778R9999 Protective frame for connecting cabinets 2
ESAS0310 2CPX078154R9999 Sheet steel door, W 300 mm, H 1000 mm 1
TZ101 2CPX010450R9999 Flange for 52 entries 5
CKDC1620 2CPX078321R9999 CombiLine S, DIN Components, Row distance 200 mm, 1 row, W 600 mm, H 200 mm 6
CKUC6020 2CPX078314R9999 CombiLine S, Measuring instruments, 4 pcs. 72x72 mm, W 600 mm, H 200 mm 2
CACP6020 2CPX078353R9999 CombiLine S, Cover, plain, W 600 mm, H 200 mm 2
CACP3060 2CPX078348R9999 CombiLine S, Cover, plain, W 300 mm, H 600 mm 1
CACP3010 2CPX078341R9999 CombiLine S, Cover, plain, W 300 mm, H 100 mm 1
CVAC1511 2CPX078269R9999 CombiLine S, Device vertical, W 300 mm, Tmax XT3, 1 device, 3/4 pole, fixed, lever 1
operation
CASWP2 2CPX078454R9999 CombiLine S, Support, wiring duct, 2 pcs 6
18
CAHW6 2CPX078459R9999 CombiLine S, Mounting profile, for wiring system, W 600 mm 6
CKBS1231 2CPX078449R9999 CombiLine S, Busbar, support, flat busbars, holder scaled, W 300 mm, 1 support 3
BR0250 No. 2 flat busbars 250A 1
