Subdistribution boards
Examples of configurations

+0
1
+01 ESBN0608
CKDD1620
+01.10
CKDD1620

+01.30
CKDD1620

+01.20
CACP6020

+01.40

TwinLine S 55 (800 x 600 x 225 mm) IP55 and internal configuration CombiLine S
Type Ord.no. Description Pcs.
ESWG0608 2CPX078568R9999 Structure TLS55, W 600 mm, H 800 mm , D 225 mm 1
ESFG0008 2CPX078598R9999 Side walls 2 pcs, D 225 mm, H 800 mm 1
ESIN0008 2CPX078422R9999 Installation set for internal configuration, H 800 mm 1
TZ101 2CPX010450R9999 Flange for 52 entries 2
ESAT0608 2CPX078179R9999 Transparent door, W 600 mm, H 800 mm 1
CKDC1620 2CPX078321R9999 CombiLine S, DIN Components, Row distance 200 mm, 1 row, W 600 mm, H 200 mm 3
CACP6020 2CPX078353R9999 CombiLine S, Cover, plain, W 600 mm, H 200 mm 1
