Consumer units
UK600 flush- & hollow wall - with N/PE quick-terminals

Article H x W x D (mm) SU Type Ord. no.
Flush-mounted consumer units, 1-row
Niche dimensions for flush-mounting 355 x 367 x 95 12 UK612N2 2CPX031369R9999
Wall cut out dimensions for hollow-wall- 328 x 340 x 88 (13)
mounting
With N/PE quick-terminals:
UK612N2 ZK51B, ZK82B, ZK113G
Flush-mounted consumer units, 2-row
Niche dimensions for flush-mounting 480 x 367 x 95 24 UK624N3 2CPX031370R9999
Wall cut out dimensions for hollow-wall- 453 x 340 x 88 (28)
mounting
With N/PE quick-terminals:
ZK51B, ZK82B, ZK144G

UK624N3
Flush-mounted consumer units, 3-row
Niche dimensions for flush-mounting 605 x 367 x 95 36 UK636N3 2CPX031371R9999
Wall cut out dimensions for hollow-wall- 578 x 340 x 88 (41)
mounting
With N/PE quick-terminals:
ZK51B, 2 x ZK113B, ZK206G

UK636N3

Flush-mounted consumer units, 4-row
Niche dimensions for flush-mounting 730 x 367 x 95 48 UK648N3 2CPX031372R9999
Wall cut out dimensions for hollow-wall- 703 x 340 x 88 (56)
mounting
With N/PE quick-terminals:
2 x ZK82B, ZK144B, ZK237G

UK648N3
Flush-mounted consumer units, 5-row
Niche dimensions for flush-mounting 855 x 367 x 95 60 UK660N4 2CPX031373R9999
Wall cut out dimensions for hollow-wall- 828 x 340 x 88 (70)
mounting
With N/PE quick-terminals:
ZK51B, 2 x ZK82B, ZK144B, ZK268G

UK660N4
> N/PE quick-terminals, see page 41
> Technical specifications UK600 trim frame dimensions, see page 60
